| EMC | FCC (47 CFR Part 15, Subpart B) CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014) RCM (AS/NZS CISPR 32: 2015) IC (ICES-003: Issue 7) KC (KN32: 2015, KN35: 2015) |
| Təhlükəsizlik | UL (UL 62368-1) CB (IEC 62368-1: 2014+A11) CE-LVD (EN 62368-1: 2014/A11: 2017) LOA (IEC/EN 60950-1) BIS (IS 13252 (Part 1): 2010/IEC 60950-1: 2005) |
| Ətraf Mühit | CE-RoHS (2011/65/EU) WEEE (2012/19/EU) Reach (Regulation (EC) No 1907/2006) |
| Mühafizə | IP67: IEC 60529-2013,IK08: IEC 62262:2002 |
| Ətraf Mühit Səs Filtrasiyası | Bəli |
| Audio Nümunə Götürmə Sürəti | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Sıxılması | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Sürəti | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Görüntü Sensoru | 1/1.8" Progressive Scan CMOS |
| Maks. Həlletmə | 2688 × 1520 |
| Min. İşıqlandırma | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Örtük Vaxtı | 1/3 s to 1/100,000 s |
| Gündüz & Gecə | 24/7 Color imaging |
| Bucaq Tənzimlənməsi | Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360° |
| DORI | 2.8 mm: D: 58 m O: 23 m R: 11 m I: 6 m 4 mm: D: 77 m O: 30 m R: 16 m I: 8 m |
| Üz Tutma | Bəli |
| Perimetr Mühafizəsi | Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle) |
| Əsas Hadisə | Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
| Əlaqələndirmə | Upload to FTP/NAS/memory card, notify surveillance center, trigger recording, trigger capture, send email |
| Ağıllı Hadisə | Line crossing detection, intrusion detection, region entrance detection, region exiting detection Scene change detection |
| Qidalanma | 12 VDC ± 25%, Ø5.5 mm coaxial power plug, reverse polarity protection, 0.54 A, max. 6.5 W PoE: 802.3af, Class 3, 36 V to 57 V, 0.22 A to 0.14 A, max. 8 W |
| Material | Base: aluminum, cover: plastic |
| Ölçülər | Ø113.6 mm × 72.6 mm (Ø4.5" × 2.9") |
| Qablaşdırma Ölçüləri | 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3") |
| Qablaşdırma ilə Çəki | Approx. 635 g (1.4 lb.) |
| Saxlama Şərtləri | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| İşə Salma və İstismar Şərtləri | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Dil | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Ümumi Funksiya | Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Əlavə İşıq Növü | Ağ İşıq |
| Əlavə İşıq Mənzili | Up to 30 m |
| Ağıllı Əlavə İşıq | Bəli |
| Geniş Dinamik Diapazon (WDR) | 130 dB |
| SNR | ≥ 52 dB |
| Gündüz/Gecə Keçidi | Day, Night, Auto, Schedule |
| Görüntü Yaxşılaşdırması | BLC, HLC, 3D DNR |
| Görüntü Parametrlərinin Keçidi | Bəli |
| Görüntü Parametrləri | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Ethernet İnterfeysi | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Daxili Yaddaş | Built-in memory card slot, support microSD card, up to 512 GB |
| Daxili Mikrofon | Bəli |
| Audio | -LS: 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Həyəcan Siqnalı | -LS: 1 input, 1 output (max. 12 VDC, 20 mA) |
| Sıfırlama Düyməsi | Bəli |
| Linza Növü | Fixed focal lens, 2.8 and 4 mm optional |
| Fokus Məsafəsi & Görüş Sahəsi | 2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 134° 4 mm, horizontal FOV 95°, vertical FOV 47°, diagonal FOV 115° |
| Linza Montajı | M16 |
| Diyafram Növü | Fixed |
| Diyafram Açıqlığı | F1.0 |
| Fokus Dərinliyi | 2.8 mm: 2.3 m to ∞ 4 mm: 3.2 m to ∞ |
| Eyni Anda Canlı Baxış | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK |
| Protokollar | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets |
| İstifadəçi/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Təhlükəsizlik | Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Müştəri | iVMS-4200, Hik-Connect, Hik-Central |
| Veb Brauzer | Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Əsas Axın | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Alt Axın | 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Üçüncü Axın | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings. |
| Video Sıxılması | Main stream: H.265/H.264/H.265+/H.264+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Sürəti | 32 Kbps to 8 Mbps |
| H.264 Növü | Baseline Profile/Main Profile/High Profile |
| H.265 Növü | Main Profile |
| Bit Sürəti Nəzarəti | CBR/VBR |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | H.264 and H.265 encoding |
| Maraq Bölgəsi (ROI) | 1 fixed region for main stream and sub-stream |
