Hikvision
0,00 ₼
| Material | Metal |
| Dimension | Ø 70 mm × 159.8 mm (Ø 2.76" × 6.29" ) |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation) |
| Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
| Language | English |
| Power Supply | 12 VDC ±25%,*You are recommended to use one power adapter to supply the power for one camera. |
| Consumption | Max. 4.8 W |
| IR Range | Up to 40 m |
| Image Sensor | 8.29 megapixel progressive scan CMOS |
| Max. Resolution | 3840 (H) × 2160 (V) |
| Min. Illumination | Color: 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/12.5 s to 1/10,000 s ,NTSC: 1/15 s to 1/10,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, Tilt:0° to 180°, Rotate: 0° to 360° |
| Signal System | PAL/NTSC |
| Slow Shutter | Max. 16 times |
| Lens Type | 2.8 mm, 3.6 mm, 6 mm fixed focal lens |
| Focal Length & FOV | 102.2° (2.8 mm), 79° (3.6 mm), 50.8° (6 mm) |
| Lens Mount | M12 |
| Image Settings | Contrast, Sharpness, Saturation, Mirror, Defog, HLC |
| Frame Rate | PAL: 8 [email protected], 5 MP@20fps, 4 MP@25fps, 1080p@25fps,NTSC: 8 MP@15fps, 5 MP@20fps, 4 MP@30fps, 1080p@30fps |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) | 120 dB |
| Image Enhancement | BLC |
| Privacy Mask | ON/OFF, 4 programmable privacy masks |
| Noise Reduction | Level 1 to 10 |
| White Balance | Auto/Manual/Natural |
| AGC | Support |
| Video Output | TVI&CVBS |
| Protection | IP67 |
