| Material | Enclosure: Plastic,Main body: Metal |
| Dimension | Φ 109.82 mm × 89.75 mm (Φ 4.32" × 3.53") |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensing) |
| Communication | HIKVISION-C |
| Language | English |
| Power Supply | 12 VDC ± 25%,*You are recommended to use one power adapter to supply the power for one camera. |
| Consumption | Max. 4.5 W |
| IR Range | Up to 20m |
| White Light Range | Up to 20 m |
| Image Sensor | 2 MP CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| Min. Illumination | 0.003 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Signal System | PAL/NTSC |
| Slow Shutter | Max. 16 times |
| Light Alarm | Yes |
| Lens Type | 2.8 mm, 3.6 mm fixed lens |
| Focal Length & FOV | 103.5° (2.8 mm), 82.6° (3.6 mm) |
| Lens Mount | M12 |
| Image Parameters Switch | STD/HIGH-SAT |
| Image Settings | Brightness, Sharpness, Mirror, Smart IR |
| Frame Rate | PAL: 1080p@25fps,NTSC: 1080p@30fps |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| Wide Dynamic Range (WDR) | ≥130 dB |
| Image Enhancement | WDR/BLC/HLC/Global |
| Privacy Mask | 4 programmable privacy masks |
| Noise Reduction | 3D DNR |
| White Balance | Auto/Manual |
| White Light | Auto/Off |
| AGC | Yes |
| Video Output | TVI only |
| Motion Detection | 4 programmable motion areas |
| Protection | IP67 |
| PIR Range | Angle: 110° |
