| Protocols | TCP/IP, IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| API | Open-ended, support ONVIF, support HIKVISION SDK and Third-Party Management Platform |
| Audio Compression | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM |
| Power Supply | 36 VDC |
| Power Consumption | 130 W Max. |
| Protection Level | IP66 Standard, 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Working Temperature | Outdoor: -40°C to 70°C (-40°F to 158°F) |
| Working Humidity | ≤ 90% |
| Dimension | Φ391.8mm×400.5mm (Φ15.43"×15.77") |
| Image Sensor | Eight 1/1.8" Progressive Scan CMOS |
| Min. Illumination | Color: 0.005 Lux@(F2.0, AGC ON), B/W: 0.0005 Lux@(F2.0, AGC ON) |
| Lens | 5.0mm/ F2.0 |
| Field of View | Horizontal : 360°, Vertical: 80° |
| Smart Image Enhancement | Digital WDR, 3D DNR, HLC |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264,Sub-Stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264 |
| Main Stream Resolution | 20:9,50Hz: 25fps (4096×1800, 3840×1680, 2720×1192),60Hz: 30fps (4096×1800, 3840×1680, 2720×1192),20:6,50Hz: 25fps (4096×1200, 3840×1080, 2720×800),60Hz: 30fps (4096×1200, 3840×1080, 2720×800) |
| Sub-Stream Resolution | 20:9,50Hz: 25fps (704×320, 512×232),60Hz: 30fps (704×320, 512×232),20:6,50Hz: 25fps (704×200),60Hz: 30fps (704×200) |
| Third Stream Resolution | 20:9,50Hz: 25fps (2048×896, 1280×560, 704×320, 512×232),60Hz: 30fps (2048×896, 1280×560, 704×320, 512×232),20:6,50Hz: 25fps (2048×600, 1280×376, 704×200),60Hz: 30fps (2048×600, 1280×376, 704×200) |
| Basic Event Detection | Motion Detection |
| Smart Event Detection | Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection |
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Min. Illumination | Color: 0.002 Lux@(F1.5, AGC ON), B/W: 0.0002 Lux@(F1.5, AGC ON), 0 Lux with IR |
| IR | IR distance: 200m; IR brightness and angle are adjustable. |
| S/N Ratio | ≥ 55 dB |
| Smart Image Enhancement | 3D DNR, 120 dB WDR, Optical Defog, HLC, Smart IR, EIS |
| Focal Length | 5.6 to 208mm, 36× optical zoom |
| Zoom Speed | Approx.6.6s (Optical Wide-Tele) |
| Horizontal FOV | 62.5° to 1.9° (Wide-Tele) |
| Min. Working Distance | 10mm to 1500mm (Wide-Tele) |
| Aperture Range | F1.5 to F4.5 |
| Pan and Tilt Range | Pan: 360°, Tilt: -15° to 90° |
| Pan and Tilt Speed | Pan Manual Speed: 0.1°/s to 210°/s (Configurable), Pan Preset Speed: 240°/s ,Tilt Manual Speed: 0.1°/s to 150°/s (Configurable), Tilt Preset Speed: 200°/s |
| Preset Number | 300 |
| Patrol | 8 patrols, up to 32 presets per patrol |
| Pattern | 4 patterns, with the recording time not less than 10 minutes per pattern |
| Park Action | Preset/ Pattern Scan/ Patrol Scan/ Auto Scan/ Tilt Scan/ Random Scan/ Frame Scan/ Panorama Scan |
| Scheduled Task | Preset/ Pattern Scan/ Patrol Scan/ Auto Scan/ Tilt Scan/ Random Scan/ Frame Scan/ Panorama Scan/ Dome Reboot/ Dome Adjust/ Aux Output |
| Power-off Memory | Support |
| 3D Positioning | Support |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264,Sub-Stream: H.265/H.264/MJPEG,Third Stream: H.265/H.264 |
| Main Stream Resolution | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),50fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720),60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream Resolution | 50Hz: 25fps (704×576, 640×480, 352×288),60Hz: 30fps (704×480, 640×480, 352×240) |
| Third Stream Resolution | 50Hz: 25fps (1920×1080, 1280×960, 1280×720, 704×576, 640×480, 352×288),60Hz: 30fps (1920×1080, 1280×960, 1280×720, 704×480, 640×480, 352×240) |
| Target Filtering | People and vehicle are classified and filtered separately. |
| Basic Event Detection | Motion Detection, Video Tampering Detection, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted, Illegal Login |
| Smart Event Detection | Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection |
| Face Capture | Detect and capture faces and upload face pictures |
| Network Interface | 1 self-adaptive Ethernet interface |
| Fiber Cable | 1 1000M FC interface, TX1310/ RX1550nm wavelength, 20 km transmission distance |
| RS-485 | Half duplex, HIKVISION, Pelco-P and Pelco-D self-adaptive |
| Alarm Input/ Output | 7-ch alarm input and 2-ch alarm output, support alarm linkage: Preset/ Patrol Scan/ Memory Card Recording/ Aux Output/ Notify Surveillance Center/ Upload to FTP/ Send Email |
| Audio Input/ Output | 1-ch audio input and 1-ch audio output. |
| Storage | Built-in memory card slot, support Micro SD/SDHC/SDXC (up to 128GB) |
| One-touch Link | Support |
| Tracking Mode | Manual/ Auto/ Mix |
| Multiple Targets Tracking | Support |
| Number of Targets | Up to 30 targets can be detected at the same time. |
| Target Switch Time | <1s |
| Calibration | Manual/ Auto |
| Tracking Duration | Up to 60 s |
| Sensitivity Settings | Support |
