Hikvision
0,00 ₼
| Mühafizə | IP54 (IEC 60529-2013) |
| Audio Sıxılması | G.711,G.722.1,G.726,MP2L2,PCM,MP3,AAC |
| Audio Bit Sürəti | 8~320 Kbps(MP3)/16 Kbps(G.726)/16 Kbps(G.722.1)/32~192 Kbps(MP2L2)/16~64 Kbps(AAC-LC)/PCM/64 Kbps(G.711ulaw/G.711alaw) |
| Audio Nümunə Götürmə Sürəti | 32kHz/16kHz/48kHz/8kHz |
| Ətraf Mühit Səs Filtrasiyası | Bəli |
| Görüntü Sensoru | [Panoramic channel] 1/2.8" Progressive Scan CMOS, [PTZ channel] 1/3" Progressive Scan CMOS |
| Min. İşıqlandırma | [Panoramic channel] Color: 0.03 Lux @ (F2.3, AGC ON), B/W: 0.01 Lux @ (F2.3, AGC ON), 0 Lux with IR, [PTZ channel] Color: 0.02 Lux @ (F1.82, AGC ON), B/W: 0.01 Lux @ (F1.82, AGC ON), 0 lux with IR |
| Örtük Sürəti | 1/30 s to 1/30,000 s |
| Yavaş Örtük | Bəli |
| Gündüz & Gecə | ICR |
| Zum | [PTZ channel] 4 × optical, 16 × digital |
| Maks. Həlletmə | [Panoramic channel] 1920 × 1080, [PTZ channel] 2560 × 1440 |
| Əsas Hadisə | Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Ağıllı Hadisə | Line crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection |
| Əlaqələndirmə | [Panoramic channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording, [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan) |
| Ümumi Funksiya | mirror,watermark,IP address filter,password protection |
| Qidalanma | DC 12V| 2A ,PoE(802.3at) 42.5-57V| 0.6A |
| İstismar Şərti | -10 °C to 50 °C (14 °F to 122 °F). Humidity 90% or less (non-condensing) |
| Material | PC |
| Ölçülər | Ø183.2 mm × 128.6 mm (Ø7.2" × 5.2") |
| Əlavə İşıq Növü | IR |
| Əlavə İşıq Mənzili | IR distance: up to 20 m |
| Görüntü Parametrləri | sharpness, saturation, brightness, contrast |
| Geniş Dinamik Diapazon (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Duman Aradan Qaldırma | Digital defog |
| Gündüz/Gecə Keçidi | Day,night,auto,schedule |
| Görüntü Yaxşılaşdırması | BLC,HLC,3D DNR |
| Məxfilik Maskası | [Panoramic channel] 24 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks |
| Regional Fokus | [Panoramic channel] No, [PTZ channel] Yes |
| Regional İşıqlandırma | Bəli |
| Görüntü Parametrlərinin Keçidi | Bəli |
| Daxili Mikrofon | 1 built-in microphone |
| Daxili Dinamik | 1 built-in speaker |
| Audio | 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω |
| RS-485 | Xeyr |
| Ethernet İnterfeysi | RJ45, self-adaptive 10M/100M Ethernet port |
| Daxili Yaddaş | Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 512 GB |
| Sıfırlama | Bəli |
| Fokus | Auto,semi-auto,manual |
| Fokus Məsafəsi | [Panoramic channel] 2 mm, [PTZ channel] 2.8 to 12 mm |
| Zum Sürəti | [PTZ channel]: approx. 3.3 s |
| FOV | [Panoramic channel] horizontal field of view: 125.3°, vertical field of view: 73.2°, diagonal field of view: 143.1°, [PTZ channel] horizontal field of view: 93.2° to 48.6°, vertical field of view: 50.3° to 27.3°, diagonal field of view: 109.7° to 55.8° |
| Diyafram Açıqlığı | [Panoramic channel] Max. F2.3, [PTZ channel] Max. F1.82 |
| API | ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS) |
| Protokollar | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTCP,RTSP,NTP,UPnP,SMTP,SNMP,IGMP,QoS,UDP,Bonjour,SSL/TLS,WebSocket,WebSockets |
| Eyni Anda Canlı Baxış | Up to 20 channels |
| İstifadəçi/Host | Up to 32 users. 3 user levels: administrator, operator, and user |
| Təhlükəsizlik | Password protection,complicated password,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),watermark,IP address filter,basic and digest authentication for HTTP/HTTPS,WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS,control timeout settings,security audit log |
| Müştəri | iVMS-4200 |
| Veb Brauzer | IE8+, Chrome31 to 44, Firefox 30 to 51, Safari8.0+ |
| Hərəkət Diapazonu (Pan) | [PTZ channel] 0° to 340° |
| Hərəkət Diapazonu (Tilt) | [PTZ channel] 0° to 90° |
| Pan Sürəti | Pan speed: configurable from 0.1° to 35°/s, preset speed: 35°/s |
| Tilt Sürəti | tilt speed: configurable from 0.1° to 30°/s, preset speed 30°/s |
| Mütənasib Pan | Bəli |
| Presetlər | 300 |
| Güc Kəsilmə Yaddaşı | Bəli |
| Park Hərəkəti | Preset |
| 3D Mövqeləndirmə | Bəli |
| PTZ Status Göstəricisi | Bəli |
| Preset Dondurma | Bəli |
| Planlaşdırılmış Tapşırıq | Preset,dome reboot,dome adjust |
| Əsas Axın | [PTZ channel] Channel 1: 50 Hz: 25 fps (1920 × 1080,1280 × 960,1280 × 720), 60 Hz: 30 fps (1920 × 1080,1280 × 960,1280 × 720) [Panoramic channel] Channel 2, 3, 4: 50 Hz: 25 fps (2560 × 1440,1920 × 1080,1280 × 960,1280 × 720), 60 Hz: 30 fps (2560 × 1440,1920 × 1080,1280 × 960,1280 × 720) |
| Alt Axın | [Panoramic channel] 50 Hz:25 fps(1920 × 1080,1280 × 960,1280 × 720,704 × 576,640 × 480,352 × 288) 60 Hz:30 fps(1920 × 1080,1280 × 960,1280 × 720,704 × 480,640 × 480,352 × 240) [PTZ channel] 50 Hz:25 fps(1920 × 1080,1280 × 960,1280 × 720,704 × 576,640 × 480,352 × 288) 60 Hz:30 fps(1920 × 1080,1280 × 960,1280 × 720,704 × 480,640 × 480,352 × 240) |
| Üçüncü Axın | [Panoramic channel] 50 Hz: 25 fps (1920 × 1080, 1280 x 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 x 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 50 Hz: [PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 x 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 x 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) |
| Maraq Bölgəsi (ROI) | 8 fixed regions for main stream |
| Video Bit Sürəti | 32 Kbps to 16384 Mbps |
| H.264 Növü | Baseline profile,Main profile,High profile |
| H.265 Növü | Main profile |
| Video Sıxılması | H.265, H.264, MJPEG |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | Bəli |
