Hikvision
0,00 ₼
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Təhlükəsizlik | UL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Ətraf Mühit | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Mühafizə | IP68, TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Partlaymadan Mühafizə | ATEX: Ex II 2GD Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db,IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db,For explosive gas atmospheres, the maximum surface temperature is 85°C; For flammable dust atmospheres, the maximum surface temperature is 80°C; IIC: for explosive gas atmospheres other than mines susceptible to firedamp; For explosive gas mixture atmospheres: Zone 1, Zone 2, Zone 21, Zone 22. |
| Korroziyadan Mühafizə | NEMA 4X (NEMA 250-2018) |
| Audio Sıxılması | G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2,PCM |
| Audio Bit Sürəti | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2) |
| Audio Nümunə Götürmə Sürəti | 8 kHz/16 kHz/32 kHz/48 kHz |
| Ətraf Mühit Səs Filtrasiyası | Bəli |
| Görüntü Sensoru | 1/1.8" progressive scan CMOS |
| Maks. Həlletmə | 1920 × 1080 |
| Min. İşıqlandırma | color: 0.0005 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Örtük Sürəti | 1/1s~1/30000 s |
| Gündüz & Gecə | ICR |
| Zum | 36 × optical, 16 × digital |
| Yavaş Örtük | Bəli |
| Üz Tutma | 1. Detects up to 10 faces simultaneously 2. Uploads face with background and closed-up face pictures 3. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face |
| Əsas Hadisə | Motion detection, video tampering alarm, exception, alarm input and output |
| Ağıllı Hadisə | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection |
| Əlaqələndirmə | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan) |
| Ağıllı İzləmə | Manual tracking, Event tracking |
| Qidalanma | 100 VAC to 240 VAC Max.100 W (Max. 15 W for IR) |
| Ölçülər | 451 mm × 258 mm × 507.5 mm (17.76" × 10.16" × 19.98") |
| Material | SUS316L with anti-corrosion surface spray treatment |
| İstismar Şərti | -40°C to 60°C (-40°F to 140°F)，Working Humidity≤ 95% |
| Kabel Uzunluğu | 1.248 m (4.09 ft.) |
| Ümumi Funksiya | Anti-flicker, heartbeat, mirror, flash log, password reset via e-mail, pixel counter, password protection, one-key reset, three streams |
| Isıtıcı | Bəli |
| Silgəc | Bəli |
| Əlavə İşıq Növü | IR |
| Əlavə İşıq Mənzili | 150 m |
| Ağıllı Əlavə İşıq | Bəli |
| İQ Dalğa Uzunluğu | 850 nm |
| Görüntü Parametrlərinin Keçidi | Bəli |
| Görüntü Parametrləri | Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser |
| Gündüz/Gecə Keçidi | auto |
| Geniş Dinamik Diapazon (WDR) | 120 dB WDR |
| SNR | ≥52dB |
| Duman Aradan Qaldırma | Optical defog |
| Görüntü Yaxşılaşdırması | HLC/BLC/3D DNR/Defog/EIS/Regional Exposure/Regional Focus |
| Məxfilik Maskası | 24 programmable polygon privacy masks, mask color or mosaic configurable |
| Ethernet İnterfeysi | 1 RJ45 10 M/100 M Ethernet |
| Daxili Yaddaş | support microSD/microSDHC/microSDXC cards, up to 256 GB |
| Audio | 1-ch audio input and 1-ch audio output |
| Həyəcan Siqnalı | 7-ch alarm input and 2-ch alarm output |
| RS-485 | 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Fokus Məsafəsi | 6.0~216 mm，36 × optical |
| FOV | Horizontal field of view: 59° to 1.98° (wide-tele) Vertical field of view: 34.16° to1.12° (wide-tele) Diagonal field of view: 67.1° to 2.3° (wide-tele) |
| Fokus | Auto/Semi-automatic/Manual |
| Diyafram Açıqlığı | F1.2 |
| Zum Sürəti | approx. 4.6 s |
| Protokollar | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| Eyni Anda Canlı Baxış | Up to 20 channels |
| API | Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| Hamar Yayım | Bəli |
| İstifadəçi/Host | Up to 32 users, 3 user levels: administrator, operator, and user |
| Təhlükəsizlik | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address) |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Müştəri | iVMS-4200, HikCentral Pro, Hik-Connect |
| Veb Brauzer | IE11, Chrome 57+, Firefox 52+, Safari 11+ |
| Hərəkət Diapazonu (Pan) | 360° endless |
| Hərəkət Diapazonu (Tilt) | From -90° to 90° (auto-flip) |
| Pan Sürəti | Configurable, from 0.1°/s to 50°/s, Preset speed: 50°/s |
| Tilt Sürəti | Configurable, from 0.1°/s to 40°/s, Preset Speed: 40°/s |
| Mütənasib Pan | Bəli |
| Presetlər | 300 |
| Preset Dondurma | Bəli |
| Patrol Skan | 8 patrols, up to 32 presets for each patrol |
| Pattern Skan | 4 pattern scans, record time over 10 minutes for each scan |
| Park Hərəkəti | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| 3D Mövqeləndirmə | Bəli |
| PTZ Status Göstəricisi | Bəli |
| Planlaşdırılmış Tapşırıq | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux Output |
| Güc Kəsilmə Yaddaşı | Bəli |
| Əsas Axın | 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Alt Axın | 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) |
| Üçüncü Axın | 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Sıxılması | Main Stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
| Video Bit Sürəti | 32 Kbps to 16384 Kbps |
| H.264 Növü | Baseline Profile/Main Profile/High Profile |
| H.265 Növü | Main Profile |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | Bəli |
| Maraq Bölgəsi (ROI) | 8 fixed regions for each stream |
