| Network Storage | Built-in 32 GB memory and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, UDP, Bonjour |
| General Function | One-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| API | ONVIF(PROFILE S,PROFILE G), PSIA, CGI, ISAPI |
| Power | 10 VDC to 30 VDC, two-core terminal block |
| Power Consumption | 12 VDC, 0.5 A, Max. 6 W |
| Working Temperature/Humidity | -20°C to 50°C (-4°F to 122°F), humidity less than 95% |
| Protection Level | IP40 |
| Dimension (L x W x H) | Camera: 60 × 60 × 120 mm (2.4” × 2.4” × 4.7”); With package: 251 × 215 × 189 mm (9.9” × 8.5” × 7.4”) |
| Main Stream | 50Hz: 50 fps (384 × 288) |
| Sub Stream | 50 Hz: 50 fps (384 × 288) |
| Image Enhancement | 3D DNR, EIS |
| Image Setting | Rotate mode, brightness, contrast and AGC adjustable by client software or web browser |
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format |
| Burning Prevention | Auto, Manual |
| Video Compression | Main stream: H.265/H.264; Sub-stream: H.265/H.264; Support custom stream |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.264+ | Main stream and sub-stream support |
| H.265 Type | Main Profile |
| H.265+ | Main stream and sub-stream support |
| Video Bit Rate | 256 Kbps to 16 Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio Bit Rate | 64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32-192 Kbps(MP2L2) |
| Exception Detection | Audio exception detection |
| Region of Interest | 4 fixed regions for main stream, sub stream |
| Temperature Range | -20°C to 150°C (-4°F to 302°F); 0°C to 550°C (32°F to 1022°F) |
| Temperature Accuracy | ± 2°C(± 3.6°F) or ± 2% (larger value) |
| Temperature measurement Type | Display Max. and Min. temperature in live view; 3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line). |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz |
| Image Sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Max. Resolution | 384 × 288 |
| Pixel Pitch | 17 μm |
| Response Waveband | 8 μm to 14 μm |
| NETD | < 40 mk (@25°C, F# = 1.0) |
| Lens (Focal Length) | 25 mm |
| Focus Mode | Auto, Manual, Semi-auto. Support Regional Focus |
| MRAD (IFOV) | 0.68 |
| Field of View | 25° × 19° |
| Min. Focusing Distance | 0.5 m |
| Aperture | F1.0 |
| External Optics Correction | Support Thermal Optical Transmittance and Manual Input External Optics Temperature; Support Calibration Coefficient calculation |
| Temperature Info. of Thermometry Rule | Real-time Output; Time Interval: 500 ms |
| Temperature Info. of Image | Real-time Output; Default is 4 fps, 32 bit × 384 × 288 per frame; 16 bit and 32 bit are selectable |
| Capture Thermal Graphic | 32 bit 384 × 288 |
| Metadata Output | Max. 50 fps (16 bit 384 × 290) |
