| Main Stream | 50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) |
| Sub-stream | 50 Hz: 25 fps (704 × 576, 352 × 288, 320 × 240) |
| Third Stream | 50 Hz: 25 fps (1280 × 720, 704 × 576, 352 × 288, 320 × 240) |
| Video Compression | Main Stream: H.265/H.264 Sub-Stream: H.265/H.264/MJPEG Third Stream: H.265/H.264/MJPEG |
| Audio Compression | G .711u/G.711a/G.722.1/MP2L2/G.726/PCM |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| API | ISAPI, HIKVISION SDK, third-party management platform, ONVIF (Profile S, Profile G, Profile T) |
| Security | User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering |
| Simultaneous Live View | Up to 20 channels |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 + |
| Network Storage | Built-in MicroSD card slot, supporting MicroSD/SDHC/SDXC card (up to 256 G), supports manual/alarm recording |
| User/Host level | Up to 32 users, 3 levels: Administrator, Operator, User |
| Web Client Language | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Power Supply | 12 VDC ± 20%, two-core terminal block PoE (802.3af, class 3) |
| Power Consumption | 12 VDC ± 20%: 0.4 A, max. 4.5 W PoE (802.3af, class 3): 42.5 V to 57 V, 0.14 A to 0.22 A, max. 5 W |
| Working Temperature/Humidity | -40 °C to 65 °C (-40 °F to 149 °F) 95% or less |
| Protection Level | IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimensions | 138.3 mm × 138.3 mm × 123.1 mm (5.45 " × 5.45" × 4.85 ") |
| Alarm Input | 1-ch inputs (0-5 VDC) |
| Alarm Output | 1-ch relay outputs, alarm response actions configurable |
| Alarm Action | SD recording/Relay output/Smart capture/FTP upload/Email linkage |
| Audio Input | 1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10% |
| Audio Output | Linear Level; Impedance: 600 Ω |
| Communication Interface | 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface |
| Image Sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Resolution | 160 × 120 (the resolution of output image is 320 × 240) |
| Pixel Interval | 17 μm |
| Response Waveband | 8 μm to 14 μm |
| NETD | Less than 40 mK (@ 25 °C,F#=1.1) |
| Focal Length | 6.2 mm |
| IFOV | 2.74 mrad |
| Field of View | 25.0° × 18.7° (H × V) |
| Min. Focusing Distance | 0.6 m |
| Aperture | F1.1 |
| Digital Zoom | ×2, ×4, ×8 |
| VCA | 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules totally. |
| Temperature Measurement | 3 temperature measurement rule types, 21 rules in total (10 points, 10 areas, and 1 line). |
| Temperature Range | -20 °C to 150 °C (-4 °F to 302 °F) |
| Temperature Accuracy | ± 8 °C (±14.4 °F) |
| Fire Detection | Dynamic fire detection, up to 10 fire points detectable. |
| Detection Range for Humans (1.8×0.5m) | 182 m |
| Detection Range for Vehicles (4.0×1.4m) | 559 m |
| Recognition Range for Humans (1.8×0.5m) | 46 m |
| Recognition Range for Vehicles (4.0×1.4m) | 140 m |
| Identification Range for Humans (1.8×0.5m) | 23 m |
| Identification Range for Vehicles (4.0×1.4m) | 70 m |
| VCA Range for Humans | 42 m |
| VCA Range for Vehicles | 126 m |
| Temperature Measurement Range for Object (2m×2m) | 132 m |
| Temperature Measurement Range for Object (1m×1m) | 66 m |
| Fire Detection Range for Object (2m×2m) | 360 m |
| Fire Detection Range for Object (1m×1m) | 180 m |
| Target Coloration | Yes. Supported in white hot and black hot mode. |
