| Main Stream | 50fps (640×512, 384×288, 352×288) |
| Sub stream | 50fps (640×512, 384×288, 352×288) |
| Third stream | 50fps (640×512, 384×288, 352×288) |
| Video compression | H.265/H.264/MJPEG, H.265+/H.264+ encoding with Baseline/Main/High Profile |
| Audio compression | G.711u/G.711a/G.722.1/MP2L2/G.726/PCM |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Simultaneous live view | Up to 20 |
| User/Host level | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security measures | User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering |
| Menu Language | English |
| Power | 24 VAC± 25%, 12 VDC± 20%, two-core terminal block |
| Power Consumption | 24 VAC± 25%: 0.92 A, 12 VDC ± 20%: 1.9 A, max. 8W (22W with De-icing Heater On) |
| Work Temperature/Humidity | -40 °C to 65 °C (-40 °F to 149 °F), 90% or less |
| Protection Level | IP66 Standard,TVS 6000V Lightning protection, surge protection, voltage transient protection |
| Dimensions | 535mm × 400mm × 171mm (21.06" × 15.75" × 6.73") |
| Image sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Pixel Interval | 17 μm |
| Response Waveband | 8 μm to 14 μm |
| NETD | less than 40mk (@25°C,F#=1.0) |
| MRAD | 0.23 mrad |
| Field of View | 8.3° × 6.64° (H × V) |
| Min. Focusing Distance | 8 m |
| Aperture | F 1.0 |
| VCA(Video Content Analysis) | 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules. |
| Temperature Measurement | 3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line). |
| Temperature Range | -20 °C to 150 °C (-4 °F to 302 °F) |
| Temperature Accuracy | ±8 °C (14.4 °F) |
| Fire Detection | Dynamic fire point detection, up to 10 fire points detectable. |
| Alarm Input | 2-ch inputs (0-5V DC) |
| Alarm Output | 2-ch relay outputs, alarm response actions configurable |
| Alarm Action | Preset/Patrol Scan/ Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage |
| Audio Input | 1 3.5mm Mic in/Line in interface. Line input: 2-2.4V[p-p], output impedance:1KΩ±10% |
| Audio Output | Linear Level; Impedance: 600Ω |
| Ethernet | 1 RJ45 10M/100M Self-adaptive Ethernet interface |
| SD Memory Card | Built-in Micro SD card slot, support Micro SD/SDHC/SDXC card (up to 128G), support manual/alarm recording |
| Analog Video Output | 1.0V [p-p]/75Ω, PAL/NTSC/BNC |
| Application Programming | Open-ended API, support ISAPI, HIKVISION SDK and third-party management platform |
| Client | iVMS-4200 |
| Web Browser | IE9+, chrome31-chrome44, Firefox 30-Firefox51, Safari 5.02+(mac) |
