| Main Stream | Thermal: 50 fps (1280 × 720, 704 × 576, 384 × 288, 352 × 288);Optical: 50Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720);Optical: 60Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream | Thermal: 50 fps (704 × 576, 384 × 288, 352 × 288);Optical: 50 Hz: 25 fps (704 × 576, 352 × 288, 176 × 144);Optical: 60 Hz: 30 fps (704 × 480, 352 × 240, 176 × 120) |
| Video Compression | H.264 (Baseline/Main/High Profile) /MJPEG/H.265, H.264+, H.265+ |
| Audio Compression | G .711u/G.711a/G.722.1/MP2L2/G.726/PCM |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| API | Open-ended API, supporting ISAPI, HIKVISION SDK, and third-party management platform, open network video interface |
| Security | User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering |
| Simultaneous Live View | Up to 20 channels |
| Web Client Language | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Wiper | No |
| User/Host level | Up to 32 users, 3 levels: Administrator, Operator, User |
| Power | PoE (802.3at, class 4), 42.5 V to 57 V, 0.35 A to 0.47 A;DC 12V, 1.6A |
| Power Consumption | 24 VAC± 25%: 0.84 A, 12 VDC ± 20%: 1.6 A, max. 20W PoE (802.3at, class 4): 42.5 V to 57 V, 0.35 A to 0.47 A |
| Work Temperature/Humidity | From -40°C to 65°C (-40°F to 149°F); Humidity: 90% or Less |
| Protection Level | IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension | 352.4 mm × 113.5 mm × 114.7 mm (13.9 " × 4.5" × 4.5 ") |
| IR Distance | Up to 40 m |
| IR Intensity and Angle | Automatically adjusted |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | Plug-in required: IE8-IE11, Chrome 41-44, Firefox 30.0-51 |
| Alarm Input | 2-ch inputs (0-5vDC) |
| Alarm Output | 2-ch relay outputs, alarm response actions configurable |
| Alarm Action | SD recording/Relay output/Smart capture/FTP upload/Email linkage |
| Audio Input | 1, 3.5 mm Mic in/Line in interface. Line input: 2 - 2.4 V [p-p], output impedance: 1 KΩ ± 10% |
| Audio Output | Linear Level; Impedance: 600 Ω |
| RS485 | 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface |
| Analog Video Output | 1.0 V [p-p]/75 Ω, BNC for thermal channel |
| Communication Interface | 1, RJ45 10 M/100 M Self-adaptive Ethernet interface. 1, RS-485 interface |
| On-board Storage | Built-in Micro SD card slot, support Micro SD/SDHC/SDXC card (up to 128G), support manual/alarm recording |
| Image Sensor | VOx Uncooled Focal Plane Arrays |
| Resolution | 384 × 288 |
| Pixel Interval | 17 μm |
| Response Waveband | 8 μm to 14 μm |
| NETD | Less than 40 mK (@ 25 °C,F#=1.0) |
| Focal Length | 10 mm |
| Focus Mode | Athermalized |
| IFOV | 1.70 mrad |
| Aperture | F1.0 |
| Field of View | 37.7°× 28.7° (H × V) |
| Min. Focusing Distance | 1.0 m |
| VCA | Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules totally. |
| Temperature Measurement | Support 3 temperature measurement rule types, 21 rules (10 points, 10 areas, and 1 line). |
| Temperature Range | -20 °C to 550 °C (-4 °F to 1022 °F) |
| Temperature Accuracy | Max (±2 °C, ±2 %) |
| Fire Detection | Dynamic fire point detection, up to 10 fire points detectable. |
| Bi-spectrum Image Fusion | Display the details of optical channel on thermal channel |
| Picture in Picture | Display partial image of thermal channel on the full screen of optical channel |
| Image Sensor | 1/2.8” Progressive Scan CMOS |
| Resolution | 1920 × 1080, 2 MP |
| Min. Illumination | Color: 0.002 Lux @(F1.5,AGC ON), B/W: 0.0002 Lux @(F1.5, AGC ON) |
| Field of View | 52.8° × 30.0°(H × V) |
| Focal Length | 6 mm |
| Focus Mode | Fixed |
| Shutter Speed | 1s to 1/100,000s |
| White Balance | Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Daylight Lamp/Sodium Lamp |
| Day & Night Mode | IR cut filter with auto switch |
| WDR | Digital |
