| Main Stream | Visible Light: 50Hz: 25fps (1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720) ,Visible Light: 60Hz: 30fps (1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720) ,Thermal: 25fps(1280 × 720), 25fps(704 × 546), 25fps(384 × 288), 25fps(352 × 288) |
| Sub stream | Visible Light: 50Hz: 25fps (704 × 576), 25fps (352 × 288) ,Visible Light: 60Hz: 30fps (704 × 480), 30fps (352 × 288) ,Thermal: 25fps(704 × 546), 25fps(384 × 288), 25fps(352 × 288) |
| API | ISAPI, HIKVISION SDK, third-party management platform, ONVIF (Profile S, Profile G, Profile T) |
| Video compression | H.265 (Main Profile) ,H.264 (Baseline/Main/High Profile) |
| Audio compression | G .711u/G.711a/G.722.1/MP2L2/G.726/PCM |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Simultaneous live view | Up to 20-ch |
| User/Host level | Up to 32 users, 3 levels: Administrator, Operator, User |
| Web Browser | Live view (plug-in allowed) : Internet Explorer 11 Live view (plug-in free) : Chrome 57.0 +, Firefox 52.0 + Local service : Chrome 57.0+, Firefox 52.0 + |
| Security measures | User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering |
| Menu Language | English |
| Power | 24 V AC± 25% |
| Power Consumption | 30W |
| Work Temperature/Humidity | From -30 °C to 60 °C (-22 °F to 140 °F), 90% or less |
| Protection Level | IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimensions | 305 mm × 185 mm × 163 mm (12.01 " × 7.28" × 6.42 ") |
| Movement Range | Pan: 360° Continuous Rotate; Tilt: From -5° to + 90° (auto flip) |
| Pan Speed | 0.1°/s to 200°/s |
| Tilt Speed | 0.1°/s to 105°/s |
| Proportional Zoom | Yes |
| Presets | 300 |
| Patrol Scan | 8; Up to 32 Presets Per Patrol |
| Pattern Scan | 4; More Than 10 Minutes Per Pattern |
| Power Off Memory | Yes |
| Park | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| PT Status | Turn On/Turn Off |
| Scheduled Task | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output |
| Image sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Pixel Interval | 17μm |
| NETD | less than 40mk (@25°C,F#=1.0) |
| MRAD | 0.68 |
| Field of View | 14.88° × 11.19° (H × V) |
| Min. Focusing Distance | 13 m |
| Aperture | F1.0 |
| Response waveband | 8μm to 14μm |
| Max. Resolution | 384 × 288 |
| Lens (focal length) | 25 mm |
| VCA(Video Content Analysis) | 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules. |
| Temperature Measurement | 3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line). |
| Temperature Range | -20 °C to 150 °C (-4 °F to 302 °F) |
| Temperature Accuracy | ±8 °C (14.4 °F) |
| Fire Detection | Dynamic fire point detection, up to 10 fire points detectable. |
| Alarm Input | Up to 7-ch Input (0-5V DC) |
| Alarm Output | Up to 2-ch Relay Output; Support Alarm Linkage |
| Alarm Action | Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage |
| Audio Input | LINE_IN Input/MIC Input; Peak: From 2 to 2.4V[p-p]; Output Impedance: 1KΩ±10% |
| Audio Output | Linear Level; Impedance: 600Ω |
| Ethernet | Built-in RJ45; 10M/100M Ethernet Interface |
| SD Memory Card | Built-in Micro SD/SDHC/SDXC Card Slot, Up to 64GB; Support Manual/Alarm Recording |
| Analog Video Output | 1.0V [p-p]/75Ω, PAL/NTSC/BNC |
| RS485 | Half-Duplex; HIKVISION, PELCO-P and PELCO-D Self-adaptive |
| Application Programming | Open-ended API, support ISAPI; Support HIKVISION SDK and Third-party Management Platform |
| Client | iVMS-4200 |
| Web Browser | IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+; Multiple Languages |
| Max. Resolution | 1920 × 1080 |
| Image Sensor | 1/2.8’’ Progressive Scan CMOS |
| Min. Illumination | Color: 0.05 lux @ (F1.2 , AGC On ),B/W : 0.01 lux @ (F1.2 , AGC On ) |
| Field of View | 65.6° to 2.46° (Wide-Tele) |
| Aperture Range | F1.2-F4.4 |
| Focus Mode | Auto / Semiautomatic / Manual |
| WDR | 120dB |
| Shutter Speed | 1s to 1/100,000s |
| Day & Night | IR Cut Filter |
| IR Distance | Up to 100 m |
| IR Intensity and Angle | Automatically adjusted |
