Hikvision
0,00 ₼
| Main Stream | Optical:50Hz:25fps(1920×1080), 25fps(1280×960), 25fps(1280×720),Optical:60Hz:30fps(1920×1080), 30fps(1280×960), 30fps(1280×720),Thermal: 50fps(640 × 512) |
| Sub stream | Optical:50Hz:25fps (704 × 576), 25fps (352 × 288), 25fps (176 × 144),Optical:60Hz:30fps (704 × 480), 30fps (352 × 240), 30fps (176 × 120),Thermal: 50fps(640 × 512) |
| Video compression | H.264 (Baseline/Main/High Profile) /MJPEG/MPEG4 |
| Audio compression | G .711u/G.711a/G.722.1/MP2L2/G.726/PCM |
| Protocols | IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP,UDP,IGMP,ICMP,DHCP, PPPoE, Bonjour |
| Simultaneous live view | Up to 20-ch |
| User/Host level | Up to 32 users, 3 levels: Administrator, Operator, User |
| Security measures | User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x access control, IP address filtering |
| Menu Language | English |
| Power | 48V DC/5A |
| Power Consumption | 220W |
| Work Temperature/Humidity | From -40°C to 60°C (-40°F to 140°F); Humidity: 90% or Less |
| Protection Level | IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimensions | 649.2 mm × 438 mm × 261.3 mm (25.56 ‘’ × 17.24 ‘’ × 10.29 ‘’) |
| Movement Range | Pan: 360° Continuous Rotate; Tilt: From -45 ° to + 45 ° (auto flip) |
| Pan Speed | Configurable, From 0.01°/s to 40°/s |
| Tilt Speed | Configurable, From 0.01°/s to 20°/s |
| Proportional Zoom | Yes |
| Presets | 300 |
| Patrol Scan | 8; Up to 32 Presets Per Patrol |
| Pattern Scan | 4; More Than 10 Minutes Per Pattern |
| Park | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output |
| PT Status | Turn On/Turn Off |
| Scheduled Task | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Doom Reboot/Doom Adjust/Aux Output |
| Image sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Pixel Interval | 17μm |
| NETD | less than 40mk(@25°C,F#=1.0) |
| MRAD | 0.57 to 0.11 mrad |
| Field of View | WIDE:20.56° x 16.51°; TELE:4.15° x 3.32° |
| Min. Focusing Distance | 2 m |
| Aperture | F1.2 |
| Response waveband | 8μm to 14μm |
| VCA(Video Content Analysis) | 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), up to 8 VCA rules. |
| Temperature Measurement | 3 temperature measurement rule types, 21 rules (10 points, 10 regions, and 1 line). |
| Temperature Range | -20 °C to 150 °C (-4 °F to 302 °F) |
| Temperature Accuracy | ±8 °C (14.4 °F) |
| Fire Detection | Dynamic fire point detection, up to 10 fire points detectable. |
| Alarm Input | Up to 7-ch Relay Input (0-5V DC) |
| Alarm Output | Up to 2-ch; Support Alarm Linkage |
| Alarm Action | Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email linkage |
| Audio Input | LINE_IN Input/MIC Input; Peak: From 2 to 2.4V[p-p]; Output Impedance: 1KΩ±10% |
| Audio Output | Linear Level; Impedance: 600Ω |
| Ethernet | Built-in RJ45; 10M/100M Ethernet Interface |
| SD Memory Card | Built-in Micro SD/SDHC/SDXC Card Slot, Up to 64GB; Support Manual/Alarm Recording |
| Analog Video Output | 1.0V [p-p]/75Ω, PAL/NTSC/BNC |
| RS485 | Half-Duplex; HIKVISION, PELCO-P and PELCO-D Self-adaptive |
| Application Programming | Open-ended API, support ISAPI; Support HIKVISION SDK and Third-party Management Platform |
| Client | iVMS-4200 |
| Web Browser | IE 7+, Chrome 18+, Firefox 5.0+, Safari 5.02+; Multiple Languages |
| Max. Resolution | 1920 × 1080 |
| Image Sensor | 1/1.8’’ Progressive Scan CMOS |
| Min. Illumination | Color : 0.005 Lux @ (F3.5, AGC ON),B/W : 0.0005 Lux @ (F3.5, AGC ON) |
| Field of View | 31.5 ° × 23.9 ° to 0.51 ° × 0.39 ° (Wide-Tele) |
| Aperture Range | F3.5 to Close |
| Focus Mode | Auto / Semiautomatic / Manual |
| WDR | Digital |
| Shutter Speed | PAL: 1-1/30,000s / NTSC: 1-1/30,000s |
| Day & Night | IR Cut Filter |
