Hikvision
0,00 ₼
| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 |
| Təhlükəsizlik | UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1 |
| Mühafizə | IP68 (IEC 60529-2013) (within 15 m underwater) |
| Görüntü Sensoru | 1/1.8" Progressive Scan CMOS |
| Maks. Həlletmə | 2560 × 1440 |
| Min. İşıqlandırma | Color: 0.001 Lux @ (F1.4, AGC ON), B/W: 0 Lux with Light |
| Örtük Vaxtı | 1 s to 1/100,000 s |
| DORI | Wide: D: 61.5 m, O: 24.4 m, R: 12.3 m, I: 6.2 m Tele: D: 151.7 m, O: 60.2 m, R: 30.3 m, I: 15.2 m |
| Əsas Hadisə | Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Ağıllı Hadisə | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection,object removal detection,scene change detection |
| Əlaqələndirmə | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture |
| Qidalanma | 36 VDC ± 20%, 0.5 A, max. 18 W, two-core terminal block PoE: IEEE 802.3at, Class 4 |
| Material | 316L and anti-corrosion coating |
| Ölçülər | 210.6 mm × 208 mm × 224 mm (8.29" × 8.19" × 8.82") |
| Qablaşdırma Ölçüləri | 700 mm × 530 mm × 365 mm (27.6" × 20.9" × 14.4") |
| Qablaşdırma ilə Çəki | Approx. 17.38 kg (38.32 lb.) |
| İşə Salma və İstismar Şərtləri | -10 °C to 60 °C (14 °F to 140 °F). Humidity 100% or less (non-condensing) |
| Dil | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Ümumi Funksiya | Anti-banding, heartbeat, mirror, flash log, password reset via email, pixel counter |
| Kabel Uzunluğu | 15 m (49.2 ft.) (included) |
| Əlavə İşıq Növü | Ağ İşıq |
| Əlavə İşıq Mənzili | Turbidity (NTU) : 0 to 5, up to 1 m, Turbidity (NTU) : 5 to 15, up to 0.5 m, Turbidity (NTU) : ＞15, up to 0.2 m |
| Görüntü Parametrlərinin Keçidi | Bəli |
| Görüntü Parametrləri | Rotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser |
| Gündüz/Gecə Keçidi | Gündüz, Gecə, Avto, Cədvəl, Həyəcan Siqnalı |
| Geniş Dinamik Diapazon (WDR) | 120 dB |
| Görüntü Yaxşılaşdırması | BLC,HLC,3D DNR,Defog |
| Şəkil Üst-üstə Qoyma | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
| SNR | ≥ 50 dB |
| Məxfilik Maskası | 8 programmable polygon privacy masks |
| Ethernet İnterfeysi | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Daxili Yaddaş | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 128 GB, *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing. |
| Fokus | Avto, Yarı-avto, Əl ilə |
| Linza Növü | Varifocal lens, motorized lens, 2.8 to 12 mm |
| Fokus Məsafəsi & Görüş Sahəsi | 2.8 to 12 mm, horizontal FOV 70.1° to 29.7°, vertical FOV 38.7° to 16.8°, diagonal FOV 81.2° to 34.0° |
| Diyafram Açıqlığı | F1.4 |
| Protokollar | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, SSL/TLS, WebSocket, WebSockets |
| Eyni Anda Canlı Baxış | Up to 20 channels |
| API | Open Network Video Interface, ISAPI, SDK, ISUP |
| İstifadəçi/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS),CVR,NVR,Auto Network Replenishment (ANR), Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Müştəri | iVMS-4200, Hik-Connect, Hik-Central |
| Veb Brauzer | Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Əsas Axın | 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Alt Axın | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Üçüncü Axın | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Video Sıxılması | Main stream: H.265/H.264 /H.265+/H.264+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264 |
| Video Bit Sürəti | 32 Kbps to 8 Mbps |
| H.264 Növü | Baseline Profile,Main Profile,High Profile |
| H.265 Növü | Main Profile |
| Bit Sürəti Nəzarəti | CBR, VBR |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | H.265 and H.264 encoding |
| Maraq Bölgəsi (ROI) | 5 fixed regions for main stream and sub-stream |
| Hədəf Kəsmə | Bəli |
