| EMC | FCC: 47 CFR Part 15, Subpart B CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EEN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014 RCM: AS/NZS CISPR 32: 2015 IC: ICES-003: Issue 7 KC: KN 32: 2015, KN 35: 2015 |
| Təhlükəsizlik | UL: UL 62368-1 CB: IEC 62368-1:2014+A11 CE-LVD: EN 62368-1:2014/A11:2017 BIS: IS 13252(Part 1):2010/ IEC 60950-1 : 2005 LOA: IEC/EN 60950-1 |
| Ətraf Mühit | CE-RoHS: 2011/65/EU WEEE: 2012/19/EU Reach: Regulation (EC) No 1907/2006 |
| Mühafizə | IP67: IEC 60529-2013 IK10: IEC 62262: 2002 (without -R) |
| Korroziyadan Mühafizə | NEMA 4X: NEMA 250-2018 |
| Audio Növü | Mono sound |
| Audio Sıxılması | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
| Audio Bit Sürəti | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)/8 to 320 Kbps (MP3) |
| Audio Nümunə Götürmə Sürəti | 8 kHz/16 kHz/32 kHz/44.1 kHZ/48 kHz |
| Ətraf Mühit Səs Filtrasiyası | Bəli |
| Görüntü Sensoru | 1/1.8" Progressive Scan CMOS |
| Maks. Həlletmə | 3840 × 2160 |
| Min. İşıqlandırma | Color: 0.002 Lux @ (F1.2, AGC ON), B/W: 0.0002 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Örtük Vaxtı | 1 s to 1/100,000 s |
| Gündüz & Gecə | IR cut filter Blue glass module to reduce ghost phenomenon |
| DORI | Wide: 2.8 to 12 mm: D: 87 m, O: 34.5 m, R: 17.4 m, I: 8.7 m 8 to 32 mm: D: 200 m, O: 79.4 m, R: 40m, I: 20 m Tele: 2.8 to 12 mm: D: 216 m, O: 85.7 m, R: 43.2 m, I: 21.6 m 8 to 32 mm: D: 580 m, O: 230 m, R: 116 m, I: 58 m |
| Yol Nəqliyyatı və Nəqliyyat Vasitəsi Aşkarlanması | Blocklist and allowlist: up to 10,000 records Captures vehicle that has no license plate Support license plate recognition of motorcycles (only in checkpoint scenario) Support vehicle attribute detection, including vehicle type, color, brand, etc. (City Street mode is recommended.) |
| Metadata | Metadata of road traffic is supported. |
| Əsas Hadisə | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal reboot, HDD full, HDD error), video quality diagnosis, vibration detection |
| Ağıllı Hadisə | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)) Scene change detection, audio exception detection, defocus detection |
| Əlaqələndirmə | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning |
| Qidalanma | 12 VDC ± 20%, 1.8 A, max. 22 W, three-core terminal block PoE: 802.3at, Type 2, Class 4, 42.5 V to 57 V), 0.5 A to 0. 4 A, max. 22 W |
| Material | 316L and anti-corrosion coating |
| Ölçülər | With -R: 240.9 mm × 145 mm × 166.6 mm (9.5" × 5.7" × 6.6")Without -R: 224 mm × 145 mm × 143.5 mm (8.8" × 5.7" × 5.6") |
| Qablaşdırma Ölçüləri | 477 mm × 235 mm × 302 mm (18.7" × 9.3" × 11.9") |
| Qablaşdırma ilə Çəki | With -R: approx. 5690 g (12.5 lb.) Without -R: approx.4700 g (10.4 lb.) |
| Saxlama Şərtləri | -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| İşə Salma və İstismar Şərtləri | -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Dil | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Ümumi Funksiya | Anti-banding, 5 streams, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Isıtıcı | Bəli |
| Silgəc | -R: Yes |
| Əlavə İşıq Növü | IR |
| Əlavə İşıq Mənzili | 2.8 to 12 mm: 60 m 8 to 32 mm: 100 m |
| Ağıllı Əlavə İşıq | Bəli |
| İQ Dalğa Uzunluğu | 850 nm |
| Görüntü Parametrlərinin Keçidi | Bəli |
| Görüntü Parametrləri | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Gündüz/Gecə Keçidi | Day, Night, Auto, Schedule, Alarm Trigger, Video Trigger |
| Geniş Dinamik Diapazon (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Görüntü Yaxşılaşdırması | BLC, HLC, Defog, 3D DNR |
| Şəkil Üst-üstə Qoyma | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Görüntü Sabitləşdirilməsi | EIS |
| Ethernet İnterfeysi | 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| Daxili Yaddaş | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
| Audio | 1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Həyəcan Siqnalı | 1 input, 1 output (max. 24 VDC, 1 A or max. 110 VAC, 500 mA) |
| RS-485 | Without -R: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) -R: does not support |
| Sıfırlama Düyməsi | Bəli |
| Wiegand | /P: 1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit) |
| Fokus Məsafəsi & Görüş Sahəsi | 2.8 to 12 mm, horizontal FOV 100.8° to 40.2°, vertical FOV 53.3° to 22.5°, diagnol FOV 122.3° to 46.2° 8 to 32 mm, horizonral FOV 40.7° to 14.6°, vertical FOV 22.3° to 8.3°, diagnol FOV 47.4° to 16.7° |
| Fokus | Auto, semi-auto, manual |
| Diyafram Açıqlığı | 2.8 to 12 mm: F1.38 to F2.5 8 to 32 mm: F1.7 |
| Protokollar | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
| Eyni Anda Canlı Baxış | Up to 20 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| İstifadəçi/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Təhlükəsizlik | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Müştəri | iVMS-4200, Hik-Connect, Hik-Central |
| Veb Brauzer | Plug-in required live view: IE10, IE11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari12+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Əsas Axın | 50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280× 720) 60 Hz: 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280× 720) |
| Alt Axın | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Üçüncü Axın | 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Dördüncü Axın | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Beşinci Axın | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Video Sıxılması | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream/Fourth stream/Fifth stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video Bit Sürəti | 32 Kbps to 16 Mbps |
| H.264 Növü | Baseline Profile/Main Profile/High Profile |
| H.265 Növü | Main Profile |
| Bit Sürəti Nəzarəti | CBR/VBR |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | H.265 and H.264 encoding |
| Maraq Bölgəsi (ROI) | 5 fixed regions for each stream |
| Hədəf Kəsmə | Bəli |
