| EMC | FCC: FCC-SDoC (ANSI C63.4, FCC Part15 sub B) CE: CE-EMC (EN 50130-4: 2011+A1: 2014, EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013) IC: IC-VoC (ICES-003 Issue 7: 2020) KC: KN 301489-1, KN 301489-17, RRA NOTICE 2017-14 (2017.12.05), RRA NOTICE 2017-19 (2017.12.28) |
| Təhlükəsizlik | CB (IEC 60950-1) CE: CE-LVD (EN 60950-1: 2006+A11: 2009+A1: 2010+A12: 2011+A2: 2013) |
| Mühafizə | IK08 (IEC 62262:2002), IP68 (IEC 60529-2013) |
| Partlaymadan Mühafizə | ATEX: II 2G Ex db IIC T6 Gb/ II 2D Ex tb IIIC T80°C Db IP68 IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80°C Db IP68 For explosive gas atmospheres, the maximum surface temperature is 85°C; For flammable dust atmospheres, the maximum surface temperature is 80°C; IIC: for explosive gas atmospheres other than mines susceptible to firedamp; For explosive gas mixture atmospheres: Zone 1, Zone 2, Zone 21, Zone 22. |
| Audio Növü | Mono sound |
| Audio Sıxılması | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
| Audio Bit Sürəti | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Nümunə Götürmə Sürəti | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Ətraf Mühit Səs Filtrasiyası | Bəli |
| Görüntü Sensoru | 1/3" Progressive Scan CMOS |
| Maks. Həlletmə | 2688 × 1520 |
| Min. İşıqlandırma | Color: 0.0125 Lux @ (F1.9, AGC ON), B/W: 0.005 Lux @ (F1.9, AGC ON), 0 Lux with IR |
| Örtük Vaxtı | 1 s to 1/100,000 s |
| Gündüz & Gecə | İQ kəsici filtr |
| DORI | Wide: D: 86 m, O: 34.1 m, R: 17.2 m, I: 8.6 m Tele: D: 192 m, O: 76.2 m, R: 38.4 m, I: 19.2 m |
| Əsas Hadisə | Motion detection (support alarm triggered by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Ağıllı Hadisə | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)) Scene change detection, audio exception detection, defocus detection, unattended baggage detection, object removal detection |
| Əlaqələndirmə | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning |
| Qidalanma | 100 VAC to 240 VAC, 0.2 A, 50/60 Hz, max. 12 W, three-core terminal block PoE: 802.3af, Class 3, 36 to 57 V, 0.3 to 0.2 A, max. 12 W |
| Material | Stainless steel 304 |
| Ölçülər | 221 mm × 174 mm × 172 mm (8.0"× 6.9" × 6.8") |
| Qablaşdırma Ölçüləri | 435 mm × 255 mm × 285 mm (17.1" × 10" × 11.2") |
| Qablaşdırma ilə Çəki | Approx. 6.20 kg (13.67 lb.) |
| Saxlama Şərtləri | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| İşə Salma və İstismar Şərtləri | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Dil | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Ümumi Funksiya | Heartbeat, mirror, anti-banding, watermark, password protection, privacy mask |
| Kabel Uzunluğu | 1.41 m (4.63 ft.) |
| Əlavə İşıq Növü | IR |
| Əlavə İşıq Mənzili | Up to 50 m |
| İQ Dalğa Uzunluğu | 850 nm |
| Ağıllı Əlavə İşıq | Bəli |
| Görüntü Parametrləri | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Gündüz/Gecə Keçidi | Day, Night, Auto, Schedule, Alarm Trigger |
| Geniş Dinamik Diapazon (WDR) | 120 dB |
| Görüntü Yaxşılaşdırması | BLC, HLC, 3D DNR, Defog, Lens Distortion Correction |
| Məxfilik Maskası | 8 programmable polygon privacy masks |
| Şəkil Üst-üstə Qoyma | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Audio | 1 input (line in), 1 output (line out) |
| Ethernet İnterfeysi | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Daxili Yaddaş | Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing. |
| Həyəcan Siqnalı | 1 alarm input, 1 alarm output |
| Sıfırlama Düyməsi | Bəli |
| Linza Növü | Varifocal lens, motorized lens, 2.8 to 12 mm |
| Fokus Məsafəsi & Görüş Sahəsi | 2.8 to 12 mm, horizontal FOV 69.7° to 30.8°, vertical FOV 38.6° to 17.4°, diagonal FOV 80.5° to 34.9° |
| Linza Montajı | Ø14 |
| Diyafram Açıqlığı | F1.9 |
| Protokollar | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP |
| Eyni Anda Canlı Baxış | Up to 20 channels |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| İstifadəçi/Host | Up to 32 users 3 user levels: administrator, operator and user |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Müştəri | iVMS-4200, Hik-Connect, Hik-Central |
| Veb Brauzer | Plug-in required live view: IE 11 Plug-in free live view: Safari12+ Local service: Chrome 57.0+, Firefox 52.0+ Not recommended: Safari 11+, Edge |
| Əsas Axın | 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2680 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Alt Axın | 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Üçüncü Axın | 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Video Sıxılması | Main stream: H.265/H.264/H.265+/H.264+ Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video Bit Sürəti | 32 Kbps to 8 Mbps |
| H.264 Növü | Baseline Profile/Main Profile/High Profile |
| H.265 Növü | Main profile |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | H.264 and H.265 encoding |
| Maraq Bölgəsi (ROI) | 5 customized regions for main stream |
| Hədəf Kəsmə | Bəli |
