| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Power Supply | 100 VAC to 240 VAC, three-core terminal block PoE (802.3at, class 4) |
| Dimensions | 513.2 × 169 × 308 mm (20.2"× 6.65\" × 12.13\") Package: 753 × 313 × 424 mm (29.65 × 12.32\" × 16.69\") |
| Power Consumption | -IZHRS: 100 VAC to 240 VAC, 0.38 A to 0.18 A, max. 22.6W; PoE (802.3at, 42.5 V to 57 V), 0.56 A to 0.42 A, max. 23.6W -IZHS: 100 VAC to 240 VAC, 0.32 A to 0.11 A, max. 18.6 W; PoE (802.3at, 42.5 V to 57 V), 0.46 A to 0.34 A max. 19.6 W |
| Heater | -H: yes |
| Wiper | With –R model supports |
| Explosion-proof Certificate | ATEX: II 2 G Ex db op is IIC T6 Gb/II 2D Ex tb op is IIIC T80°C Db IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80°C Db For explosive gas atmospheres, the maximum surface temperature is 85°C; For flammable dust atmospheres, the maximum surface temperature is 80°C; IIC: for explosive gas atmospheres other than mines susceptible to firedamp; For explosive gas mixture atmospheres: Zone 1, Zone 2, Zone 21, Zone 22. |
| Image Sensor | 1/1.8″ Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @(F1.2, AGC ON), 0.014Lux @(F1.4, AGC ON), 0 Lux with IR on |
| Shutter Speed | 1 s to 1/100,000 s |
| Slow Shutter | Support |
| DNR | 3D DNR |
| WDR | Digital WDR |
| Day & Night | IR cut filter |
| Lens | 2.8 mm to 12 mm, F1.4, horizontal FOV: 70° to 34°, vertical FOV: 52° to 24°, diagonal FOV: 90° to 41° |
| Auto-Iris | DC drive |
| Focus | Auto |
| Image Enhancement | BLC/3D DNR/Defog/EIS |
| Target Cropping | Yes |
| Day/Night Switch | Auto/Schedule/Triggered by Alarm In |
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Image Settings | Support rotate mode. Saturation, brightness, contrast, sharpness, white balance, and AGC are adjustable by client software or web browser |
| Sub-Stream | 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240) |
| ROI (Region of Interest) | Support 4 customized region for each stream, and face dynamic tracking |
| Max. Resolution | 2592 × 1944 |
| Main Stream | 50Hz: 25fps (2592 × 1944, 2560 × 1920, 2048 × 1536), 50fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (2592 × 1944, 2560 × 1920, 2048 × 1536), 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Third Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 ×240) |
| Communication Interface | 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port, Camera with no wiper also supports RS-485 |
| Alarm | 2 alarm input, 2 alarm output (up to 24 VDC, 1 A or 110 VAC, 500 mA) |
| Video Output | 1Vp-p Composite Output(75Ω/BNC) |
| On-board Storage | Built-in microSD/SDHC/SDXC slot, up to 128 GB *You are recommended to purchase memory card together with the product if needed. After ordering, the memory card will be installed to product during manufacturing. |
| EMC | FCC: FCC-SDoC(ANSI C63.4,FCC Part15 sub B） CE: CE-EMC(EN 50130-4:2011+A1:2014,EN 55032:2015,EN 61000-3-2:2014,EN 61000-3-3:2013） IC: IC-VoC(ICES-003 Issue 7:2020) |
| Safety | CB: IEC 60950-1 CE: CE-LVD(EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013) LOA: SANS IEC60950-1 |
| Chemistry | CE: CE-RoHS(RoHS Directive 2011/65/EU+2015/863) |
| H.264+ | support |
| H.265+ | support |
| H.264 Type | Baseline profile/main profile/high profile |
| Video Compression | Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| H.265 Type | Main Profile |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Face Detection | Human face appears in the image can be detected and trigger linkage method |
| Exception Detection | Scene change detection, defocus detection, audio exception detection |
| Line Crossing Detection | Cross a pre-defined virtual line |
| Intrusion Detection | Enter and loiter in a pre-defined virtual region |
| Behavior Analysis | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection |
| Region Entrance | Enter a pre-defined virtual region from the outside place |
| Region Exit | Exit from a pre-defined virtual region |
| Unattended Baggage | Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal | Objects removed from the pre-defined region, such as the exhibits on display. |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio I/O | 3.5 mm audio input (line in), 3.5 mm audio output (line out), stereo |
| IR Range | 2.8 mm to 12 mm lens: up to 80 m (262.5 ft.) |
