| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Simultaneous Live View | Up to 20 channels |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK, Ehome |
| User/Host | Up to 32 users 3 levels: Administrator, Operator and User |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, security audit log |
| Network Storage | Support microSD/SDHC/SDXC card (256 G), local storage and NAS (NFS,SMB/CIFS), ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | IE8+, Chrome 41.0-44, Mozilla Firefox30.0-51, Safari8.0-11 |
| Power | -IVSM: 24 VDC, 0.31 A, max. 7.4 W, 9 to 36 VDC, PoE (36 to 57 VDC, 802.3 af), Class 3, 0.22 A to 0.13 A, max. 7.8 W, reverse polarity protection, two-core molex -IVS: 24 VDC, 0.31 A, max. 7.4 W, 9 to 36 VDC, PoE (36 to 57 VDC, 802.3 af), Class 3, 0.22 A to 0.13 A, max. 7.8 W, reverse polarity protection, Ø5.5mm coaxial power plug -IVM/ND: PoE: 36 to 57 VDC, 802.3 af, Class 3, 0.22 A to 0.13 A, max: 7.8W, 4-core M12 |
| Dimension | 230 mm × 100 mm × 50 mm (9.1" × 3.9" × 2" ) |
| Package Dimension | 280 mm × 135 mm × 135 mm (11" × 5.3" × 5.3") |
| With Package Weight | Approx. 960 g (2.1 lb) |
| Startup and Operating Conditions | -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Language | 32 languages. English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function | Anti-flicker, heartbeat, mirror, password protection, watermark, IP address filter |
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Max. Resolution | 1920 × 1200 |
| Min. Illumination | Color: 0.002 Lux @ (F1.2, AGC ON), 0.007 Lux @ (F2.25, AGC ON) B/W: 0.0002 Lux @ (F1.2, AGC ON), 0.0007 Lux @ (F2.25, AGC ON) |
| Shutter Time | 1/25 s to 1/100,000 s |
| Day & Night | IR Cut Filter |
| Angle Adjustment | Pan: 0°, Tilt: 0° to 25°, Rotate: 0° |
| Focal Length & FOV | 2 mm, horizontal FOV 108°, vertical FOV 84°, diagonal FOV 117.5° |
| Lens Mount | M12 |
| Aperture | F2.25 |
| Supplement Light Type | IR |
| Supplement Light Range | Up to 3 m |
| IR Wavelength | 850 nm |
| Main Stream | 50Hz: 25fps (1920 × 1200, 1440 × 900) 60Hz: 30fps (1920 × 1200, 1440 × 900) |
| Sub-Stream | 50Hz: 25fps (704 × 576, 640 × 480) 60Hz: 30fps (704 × 480, 640 × 480) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Scalable Video Coding (SVC) | H.265 and H.264 support |
| Region of Interest (ROI) | 4 fixed regions for main stream and sub-stream |
| Image Settings | Saturation, brightness, contrast, sharpness are adjustable by client software or web browser |
| Day/Night Switch | Day/Night/Auto/Schedule/Triggered by alarm input (-S) |
| Image Enhancement | HLC, BLC, 3D DNR, defog |
| Video Output | -IVS: 1Vp-p composite output (75 Ω/CVBS), only for adjustment |
| Ethernet Interface | -IVS: 1 RJ45 10M/100M Ethernet port -IVSM, -IVM/ND: M12 aviation plug, 4-core 10M/100M Ethernet port |
| On-Board Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Built-in Microphone | Yes |
| Audio | -IVS: 1 input (line in, two-core terminal block), 1 output (two-core terminal block), mono sound |
| Alarm | -S: 2 inputs, 2 outputs (max. 12 VDC, 30mA) |
| RS-485 | -IVS: 1 RS-485 interface (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Reset Key | Yes |
| Basic Event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event | Audio exception detection, defocus detection |
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KV (KN 32: 2015, KN 35: 2015) |
| Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | IK08 (IEC 62262:2002), IP66 (IEC 60529-2013) |
| Automotive and Railway | EN 50155-2017; E-MARK, R118, EN45545, 50121-3-2 |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2) |
| Audio Sampling Rate | 8kHz/16kHz/32kHz/44.1kHz/48kHz |
| Environment Noise Filtering | Yes |
| People Counting | Counts people entering and exiting separately Supports real-time uploading and uploading by statistic cycle Sends email reports on daily, weekly, monthly or annually basis Supports target filtering by height |
