| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Simultaneous Live View | Up to 20 channels |
| API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| User/Host | Up to 32 users3 levels: Administrator, Operator and User |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, RTP/RTSP over HTTPS, control timeout settings, TLS 1.2 |
| Network Storage | NAS(NFS, SMB/ CIFS) |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | Plug-in required live view: IE8+; Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+; Local service: Chrome 41.0+, Firefox 30.0+ |
| Power | 12 VDC, 0.9 A, max. 10 W, Φ5.5 mm coaxial power plug POE: 802.3af, 36 V to 57 V, 0.3 A to 0.2 A, max. 10 W |
| Dimension | 164.3 × 84.6 × 67.4 mm (6.5" × 3.3" × 2.7") |
| Package Dimension | 227 × 172 × 125 mm (8.9" × 6.8" × 4.9") |
| With Package Weight | 1053g (2.3 lb.) |
| Startup and Operating Conditions | -30° to 60° (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| General Function | mirror||password protection||watermark||IP address filter||one-key reset||anti-flicker||heart |
| Web Client Language | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Image Sensor | 1/2.5" Progressive Scan CMOS |
| Max. Resolution | 3840 × 2160 |
| Min. Illumination | Color: 0.056 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Time | 1s to 1/100, 000 s |
| Day & Night | ICR Cut |
| Angle Adjustment | P: -90° to 90°; T: 0° to 60° (2.8mm), 0° to 70° (4/6mm); R: 0° to 355° |
| Focal Length & FOV | 2.8mm @ F2.0: horizontal FOV 103°, vertical FOV 53°, diagonal FOV 124°; 4 mm @ F2.0: horizontal FOV 79°, vertical FOV 41°, diagonal FOV 94°; 6 mm @ F2.0: horizontal FOV 50°, vertical FOV 27°, diagonal FOV 58° |
| Lens Mount | M12 |
| Aperture | F2.0 |
| Supplement Light Range | Up to 10m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850nm |
| Main Stream | 50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720); 60 Hz: 24fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (640 × 480, 704 × 576); 60 Hz: 24fps (640 × 480, 704 × 480) |
| Video Compression | H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.265 and H.264 support |
| Region of Interest (ROI) | 4 fixed regions for each stream |
| Image Parameters Switch | Yes |
| Image Settings | Saturation||brightness||contrast||sharpness||white balance |
| Day/Night Switch | Day, Night, Auto, Schedule, Triggered by Alarm In (-S) |
| Wide Dynamic Range (WDR) | 120dB |
| Image Enhancement | BLC||HLC||Defog||EIS||3D DNR |
| Privacy Mask | Yes |
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Ethernet Interface | -I, -IS, -I/ND: 1 RJ45 10M/100/100M self-adaptive Ethernet port -IM, -IM/ND: 1 M12 10M/100M self-adaptive Ethernet port |
| On-Board Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Audio | Without -S: 2 built-in mics -S: 2 built-in mics, 1 line in, 1 line out |
| Alarm | -S: 1 input, 1 output (max. 36 VDC, 30mA) |
| RS-485 | -S: 1 RS-485 interface, half duplex |
| Reset Key | Yes |
| Smart Event | No |
| Linkage | Linkage Method |
| EMC | FCC(47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM(AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | Ingress protection: IP67(IEC 60529-2013), IK10(IEC 62262:2002) |
| Automotive and Railway | EN50155-2017 (EN 50155:2017, EN 50121-3-2:2016, IEC 60068-2-1:2007, IEC 60068-2-2:2007, IEC 60068-2-30:2005, IEC 60068-2-64:1993, IEC 61373:1999 ), EN45545 (EN 45545-2:2013+A1:2015), E-MARK (ECE R10) |
| Other | R118 |
| Audio Type | Stereo |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Audio Sampling Rate | 8 kHz/16 kHz/32kHz/44.1kHz/48kHz |
| Environment Noise Filtering | Yes |
| Basic Event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
