| Transmission Speed | Ethernet: 10 Mbps (Half Duplex) / 20 Mbps (Full Duplex),Fast Ethernet: 100 Mbps (half-duplex)/200 Mbps (full-duplex),Gigabit Ethernet: 2000 Mbps (full-duplex) |
| Transmission Medium | Ethernet: CAT3 or better UTP/STP cable,Fast Ethernet: CAT5 or better UTP/STP cable,Gigabit Ethernet: CAT5E or CAT6 UTP/STP cable (recommended) |
| LED Indicator | 1 * power LED,16 * Link/Act LED |
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE802.3ab, IEEE 802.3x |
| Operating Temperature | 0°C - 40°C |
| Storage Temperature | -40°C – 70°C |
| Power Supply | Input: 100-240 V AC, 50/60 Hz, 0.3 A,Output: 9 V DC, 1 A, |
| Storage Humidity | (5-90) % RH, non-condensing |
| Power Source | 2 kV |
| Dimension | 440mm×178.8mm×44mm |
| Operating Humidity | (10-90) % RH, non-condensing |
| Power Consumption | ≤12w |
| PoE Port | 16*10/100/1000Mbps auto-negotiation RJ45 ports |
| Store-and-forward | 8 k |
| Max. Forwarding Rate | Ethernet: 14881 pps one port,Fast Ethernet: 148810 pps one port,Gigabit Ethernet: 1488100 pps one port |
| MAC Address Table | 4 k |
| MAC Address Learning | Automatic learning/Aging |
| Backplane Bandwidth | 32 Gbps |
| Uplink Port | Port 15 and Port 16 |
| RJ45 Port | 4 kV |
| Port Loopguard | Supported |
| LED Indicator | 1 * power LED,16 * Link/Act LED |
