| Power supply | 12 VDC, 2-pin connector |
| Working temperature | -10 to +55ºC |
| Working humidity | 10 to 90 % |
| Consumption | ≤ 6 W |
| (W × D × H) | 114 × 47.5 × 127.5 mm (4.5" ×1.9" ×5.0") |
| Network interface | 1, RJ45 10/100 M self-adaptive Ethernet interface |
| Two-way audio input | 1, 3.5 mm interface (audio input multiplex) |
| Serial interface | 1, RS-485, half-duplex 1, RS-232 |
| Alarm in/out | Alarm in：1-ch Alarm out：1-ch |
| Network protocols | 1, RJ45 10/100 M self-adaptive Ethernet interface |
| Capacity | 4 TB for network single hard disk, 128 GB for micro SD card |
| Video input | 1-ch, VGA 1-ch, HDMI |
| HDTVI input | N/A |
| AHD input | N/A |
| HDCVI input | N/A |
| CVBS input | N/A |
| Audio input | 1-ch, 3.5 mm interface (two-way audio multiplex) |
| Audio output | 1-ch, 3.5 mm interface (linear, 600Ω) Video |
| Synchronous playback | N/A |
| Video compression | H.264/MJPEG |
| Audio compression | G.711u/G.711a/AAC |
| Main stream | Encoding at HD resolution of 1080p/720p/UXGA, etc. |
| Frame rate | 1/16 FPS to full frame rate (full frame rate includes 25/30/50/60 frames, depending on input signal) |
| Video bit rate | 32 Kbps to 8192 Kbps, up to 16 Mbps |
| Audio bit rate | 16Kbps/128Kbps |
| Dual stream | Dual stream Sub stream resolution: WD1/4CIF/2CIF/CIF/QCIF |
