Hikvision

DS-MCW407

Name: REPAIRAZ MMC
Address: Qurban Abbasov 29, Bakı, AZ
Telephone: +994773394100

0,00 ₼

1080p HD recording.
The recorded videos can be uploaded to the central video platform via 4G wireless communication.
Dual positioning modules of GPS and Beidou. The location information can be uploaded to the command center in real time.
Supports IR night vision. Even in the dark scene, the facial features of the persons in the scene can be recognized clearly.
Tri-proof design to support all-weather filed operation.
Built-in battery with large capacity, supporting longer working hour.
Small size, light weight, and convenient to carry.
Large recording button for convenient operation.

Az qalıb

WhatsApp ilə al

General

Operating System	Linux
Laser Positioning	Supported
Indicator	Charging indicator;Working indicator
Vibration	Not supported
Button	On/Off, Record, capture, tape, PTT, alarm, Fn, menu, up, down, OK
Product Weight	159.5 g (0.4 lb.)
Product Dimension	82.6 × 58 × 29 mm (3.3 × 2.3 × 1.1 inch)
Package Weight	496 g (1.1 lb.)
Package Dimension	188 × 136 × 70.5 mm (7.4 × 5.4 × 2.8 inch)
Ingress Protection	IP68
Drop Protection Performance	Drop it twice for each side (6 sides in total) from the height of 2 m on the cement ground.
Power Supply Mode	Battery power supply
Working Temperature	-20 ℃ to 55 ℃ (-4 °F to 131 °F)
Working Humidity	≤ 90%

Kamera

Sensor Type

1/3" CMOS

Lens

Lens Focal Length	2.4 mm
Lens Aperture	F2.2

Video

Stream Type	Main stream;Sub-stream
Main Stream Resolution	1920 × 1080;1280 × 720;720 × 576
Sub-Stream Resolution	1280 × 720;720 × 576
Main Stream Frame Rate	25 fps
Sub-Stream Frame Rate	5 fps, 15 fps, 25 fps
Video Compression	H.264;H.265
Record Resolution	720 × 576,1280 × 720,1920 × 1080
Image Resolution	5M;16M;30M;40M
Image Format	JPEG


Horizontal FOV	125°
Day/Night Switch	IR cut filter with auto switch (You can see human face within 3 m at night.)
White Balance	AWB
Digital Zoom	× 4

Audio

Audio Compression

G.722.1;PCM

Battery

Dismountable Battery	Not supported
Battery Capacity	3,220 mAH
Battery Life for Record	Recordable not less than 11 hours in 1080p resolution

Storage

Embedded Storage Capacity

Max. 256 GB

Screen

Screen Size	2.0 inch
Resolution	320 × 240
Material	TFT

Network and Connection

Dial-up	FDD -LTE B1;FDD -LTE B3;FDD -LTE B8;WCDMA B1;WCDMA B8;GSM 900;GSM 1800;FDD -LTE B7;FDD -LTE B20
Wi-Fi Protocol	802.11b;802.11g;802.11n
Wi-Fi Working Mode	STATION
Wi-Fi Frequency Range	2.412 to 2.472 GHz
Positioning	GPS;Beidou
Bluetooth	4.0

Light Supplement

IR	Supported
White Light	Supported

Peripheral Device Interface

Charging Interface	MiniUSB
External Interface	USB 2.0
Loudspeaker	Supported
MIC	Supported
SIM Card Slot	1 (Nano-SIM)
