| DC VOLTAGE | 48V |
| CONSTANT CURRENT REGIONNote.2 | 24~48V |
| RATED CURRENT(forBETypeonly) | 2.8A |
| RATED POWER | 100VAC~180VAC (ForAlltheTypes) 105W 200VAC~305VAC (ExceptforBEType) 150.2W (ForBETypeonly) 134.4W |
| RIPPLE & NOISE (max.) Note.3 | 250mVp-p |
| VOLTAGE ADJ. RANGE | AdjustableforA/AB-Typeonly(viathebuilt-inpotentiometer) 43.2~52.8V |
| CURRENT ADJ. RANGE | AdjustableforA/AB-Typeonly(viathebuilt-inpotentiometer) 1.56~3.13A |
| VOLTAGE TOLERANCE Note.4 | ±2.0% |
| LINE REGULATION | ±0.5% |
| LOAD REGULATION | ±0.5% |
| AUXILIARY DC OUTPUT | Nominal15V(deviation11.5~15.5V)@0.3AforBE-Typeonly |
| SETUP, RISE TIME Note.6 | 1600ms, 80ms/115VAC 500ms,100ms/230VAC |
| HOLD UP TIME (Typ.) | 10ms/115VAC, 230VAC |
| RATEDCURRENT | 3.13A |
| VOLTAGE RANGE Note.5 | 100~ 305VAC 142~431VDC (Please refer to STATIC CHARACTERISTIC\" section)" |
| FREQUENCY RANGE | 47~63Hz |
| POWER FACTOR | PF≧0.97/115 VAC, PF≧0.95/230 VAC, PF≧0.92/277 VAC@full load (Please refer to POWER FACTOR(PF) CHARACTERISTIC\" section)" |
| TOTAL HARMONIC DISTORTION | THD<20%(@load≧50%/115 VC; @load≧60%/230 VAC; @load≧75%/277 VAC) (Please refer to“TOTAL HARMONIC DISTORTION(THD)”section) |
| EFFICIENCY (Typ.) | 90% |
| EFFICIENCY (Typ.)(forBETypeonly) | 88% |
| AC CURRENT | 1.7 A/115 VAC 0.9 A/230 VAC 0.7 A/277 VAC |
| INRUSH CURRENT (Typ.) | COLD START 65 A(twidth=550 μ s measured at 50% Ipeak) at 230 VAC ; Per NEMA 410 |
| MAX .No. of PSUs on 16A CIRCUIT BREAKER | 3 units (circuit breaker of type B)/ 6 units (circuit breaker of type C) at 230 VAC |
| LEAKAGE CURRENT | <0.75 mA/277 VAC |
| NO LOAD / STANDBY POWER CONSUMPTION | No load power consumption<0.5W for Blank/A/Dx/D2-Type Standby power consumption <0.5W for B/AB/DA-Type |
| OVER CURRENT | 95~108% Constant current limiting, recovers automatically after fault condition is removed |
| SHORT CIRCUIT | Hiccup mode, recovers automatically after fault condition is removed |
| OVER VOLTAGE | 54~62V Shut down output voltage, re-power on to recover |
| OVER TEMPERATURE | Shut down output voltage, re-power on to recover |
| WORKING TEMP. | Tcase=-40~+90℃ (Please refer to“ OUTPUT LOAD vs TEMPERATURE”section) |
| MAX. CASE TEMP. | Tcase=+90℃ |
| WORKING HUMIDITY | 20~95% RH non-condensing |
| STORAGE TEMP., HUMIDITY | -40~+80℃, 10~95% RH |
| TEMP. COEFFICIENT | ±0.03%/℃ (0~60℃) |
| VIBRATION | 10~500 Hz, 5G 12min./1cycle, period for 72min. each along X,Y,Z axes |
| SAFETY STANDARDS | UL8750(type”HL”)(except for BE-type),CSA C22.2 No. 250.13-12; IEC/EN/AS/NZS 61347-1,IEC/EN/AS/NZS 61347-2-13 independent, EN62384,BIS IS15885(for 12/12B/12DA/24/24B/24DA/36A/42/42A/48A/54 only), EAC TP TC 004,GB19510.1, GB19510.14; IP65 or IP67; KC61347-1, KC61347-2-13 approved |
| DALI STANDARDS | Compliance to IEC62386-101,102,207 for DA-Type only |
| WITHSTAND VOLTAGE | I/P-O/P:3.75KVAC I/P-FG:2.0KVAC O/P-FG:1.5KVAC |
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/ 500VDC / 25℃/ 70%RH |
| EMC EMISSION | Compliance to EN55015, EN61000-3-2 ClassC(@load ≧ 60%); EN61000-3-3; GB17743 , GB17625.1 , EAC TPTC020 ; KCKN15 ,KN61547 |
| EMC IMMUNITY | Compliance to EN61000-4-2,3,4,5,6,8,11 ; EN61547 , light industry level (surge immunity Line-Earth 6KV, Line-Line 4KV),EAC TP TC020 ; KC KN 15,KN 61547 |
| MTBF | 899.8K hrs min. Telcordia SR-332 (Bellcore) 313.66 Khrs min.MIL-HDBK-217F(25℃) |
| DIMENSION | 219*63-35.5mm (L*W*H) |
| PACKING | 0.95Kg ; 16pcs/16.0kg/0.77CUFT |
