Recording

Recording Schedule	64
Recording Schedule Template	32

Hardware Specifications

CPU	Intel® Core™ i3-12100
Memory	1 × 8GB 2666MHz DDR4 UDIMM
Hard Disk	M.2 256GB SATA Class 20 solid state drive
Network	Integrated Intel I219-LM Ethernet LAN 10/100/1000
GPU Card	Integrated Intel® UHD Graphics 730
Package Dimensions	29cm × 9.26cm × 29.2cm (11.42” × 3.7” × 11.5”)

Devices and Resources

*Cameras Including up to 4 ANPR Cameras and up to 2 Cameras with Face Capture Function**	64
*Managed Device IP Addresses Including Encoding Devices, Access Control Devices, and Security Control Devices**	128
Indoor Station	8
Alarm Inputs (Including Zones of Security Control Devices)	32
Alarm Outputs	32
ANPR Cameras	4
Cameras with Face Capture Function	2
Security Radars	2
Areas	64
Cameras per Area	32
Alarm Inputs per Area	16
Alarm Outputs per Area	16

Event and Alarm

Event and Alarm Rules	128
*Events or Alarms Sent to Clients The clients include Control Clients and Mobile Clients**	5/s
Storage of Events or Alarms without Pictures	5/s 8 Clients/s
Notification Schedule Templates	100


Picture Storage *Including event/alarm pictures, face pictures, and vehicle pictures.

5/s

Reports

Regular Report Rules	64
Event or Alarm Rules in One Event/Alarm Report Rule	32
Records in One Sent Report	10,000 or 10 MB
*Resources Selected in One Report With this limitation, you can generate a neat and clear report via the Control Client and it costs less time.**	20

Users and Roles

Concurrent Accesses via Web Clients and Control Clients	8
Concurrent Accesses via Mobile Clients	8
Users	8
Roles	8

Face Analysis

Persons with Profiles for Face Comparison	10000
Face Comparison Groups	16
Persons in One Face Comparison Group	1000

Data Storage

Data Retention Period

Stored for 6 Months

Vehicle (ANPR)

Vehicle Lists	50
Vehicles per Vehicle List	500

Entrance and Exit

Lanes	4
Cards Linked with Vehicles	2500
Vehicle Passing Frequency in Each Lane	1 Vehicle/s
Entrance/Exit Station	4

Access Control

Persons with Credentials for Access Control	3000
Total Credentials (Card + Fingerprint)	15000
Cards	15000
Fingerprints	12000
Profiles	3000
Access Points (Doors+Outdoor Station)	8
Access Groups	32
Persons in One Access Group	3000
Access Levels	16
Access Schedules	32

1 / 3

Hikvision

HikCentral-Workstation/64/i3(B)

0,00 ₼

Home Page● Providing two predefined Home page modes on Web Client, including system installation and management mode, security control and management mod● Supports customizing Home page mode on Web Cliente● Supports customizing control panel on Control Client● Supports switching Home page mode for visualization and non-visualization managemen● Providing different report dashboards for resource status, access records, vacant parking spaces, alarms, etc., on the Home page of Web Clientt
Wizard● Providing wizards for video management, access control, vehicle management, alarm detection on Web Client
Live View and Playback● Custom window division configurable● Viewing maps and real-time events during live view and playback● Stream type self-adaptive, transcoded playback, and frame- extracting playback● Fisheye dewarping of multi-channel● Controlling PTZ in visualization way● Supports decoding stream from cameras with high-definition, such as PanoVu series camera
Visual Tracking
Recording and Storage:● Recording schedule for continuous recording, event recording and command recording ● Storing videos on encoding devices ● Providing video copy-back ● Storing alarm pictures on NVRs
Event Management:● Camera linkage, alarm pop-up window and multiple linkage actions ● Multiple events for video surveillance, access control, resource group, resource maintenance, etc.
Access Control, and Video Intercom:● Setting schedules for free access status and access forbidden status of doors ● Supports multiple access modes for both card reader authentication and person authentication ● Setting access groups to relate persons, templates, and access points, which defines the access levels of different persons ● Supports advanced functions such as multi-factor authentication, anti-passback, and multi-door interlocking ● Controlling door status in real-time ● Calling indoor station by the Control Client ● Calling the platform by door station and indoor station, and answering the call by the Control Client
Security Control:● Real-time alarm management for added security control panels ● Adding zone as hot spot on E-map and viewing the video of the linked camera ● Event and alarm linkage with added cameras, including pop-up live view, captured picture ● Subscribing the events that the Control Client can display in real-time ● Acknowledging the received alarm on the Control Client
Entrance and Exit Control:● Managing parking lot, entrances and exits, and lanes. Supports linking a LED screen with lane for information display ● Setting entry & exit rules for vehicles in the vehicle lists as well as vehicles not in any vehicle lists ● Entrance and exit control based on license plate recognition, card, or video intercom ● Viewing real-time and history vehicle information and controlling barrier gate manually on the Control Client
Access Control, and Video Intercom:● Setting schedules for free access status and access forbidden status of doors ● Supports multiple access modes for both card reader authentication and person authentication ● Setting access groups to relate persons, templates, and access points, which defines the access levels of different persons ● Supports advanced functions such as multi-factor authentication, anti-passback, and multi-door interlocking ● Controlling door status in real-time ● Calling indoor station by the Control Client ● Calling the platform by door station and indoor station, and answering the call by the Control Client
Temperature Screening:● Displaying the skin-temperature and whether wearing a mask or not about the recognized persons in real time ● Triggering events and alarms when detects abnormal temperature and no mask worn ● Viewing reports about skin-surface temperature and mask-wearing
Face and Body Recognition:● Displaying the information of the recognized persons in real-time ● Searching history records of recognized persons, including searching in captured pictures, searching matched persons, searching by features of persons, and searching frequently appeared persons
Network Management:● Managing network transmission devices such as switches, displaying the network connection and hierarchical relationship of the managed resources by a topology ● Viewing the network details between the device nodes in the topology, such as downstream and upstream rate, port information, etc. and checking the connection path ● Exporting the topology and abnormal data to check the device connection status and health status
