Hikvision

HM-TD1018-1/QR

Name: REPAIRAZ MMC
Address: Qurban Abbasov 29, Bakı, AZ
Telephone: +994773394100

0,00 ₼

160× 120 resolution, 12 μm, VOx UFPA, NETD < 50 mK (25°C, F1.1).
Built-in Radar to support Fall Detection
Support Out of Room Detection, Out of Bed Detection, Exit without Return and People Overstay Detection.
Audio exception alarm for alert when the elderly and patients scream
Support built-in mic and built-in speaker
Work environment: -20℃~50℃，＜95% RH
Main application: the bedroom of nursing home

Az qalıb

Main Stream

Thermal:

25 fps (1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240)

Sub-stream

Thermal:

25 fps (704 × 576, 352 × 288, 320 × 240)

Video Compression

H.264/H.265/MJPEG, H.265/MJPEG encoding support Main Profile, H.264 support Baseline/Main/High Profile

Protocols	IPv4,HTTP,HTTPS,Qos,FTP,SNMP,DDNS,TCP,PPPoE,RTSP,UPnP
Network Storage	MicroSD/SDHC/SDXC card (up to 256 G) local storage
API	ISAPI, HIKVISION SDK, and third-party management platform, Open Network Video Interface (Profile S, Profile G)
Simultaneous Live View	Up to 20 channels
User/Host level	Up to 32 users, 3 levels: Administrator, Operator, User
Security	User authentication (ID and Password), MAC address binding, HTTPS encryption, IEEE 802.1x(EAP-MD5, EAP-TLS), access control, IP address filtering
Client	iVMS-4200/EZVIZ/HIK-CONNCET/HIK-CENTRAL
Web Browser	Internet Explorer 11+, Chrome 18.0 +, Firefox 5.0 +, Safari5.02+

Web Client Language	32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Power Supply	DC 12 V（±20%）：0.5 A, max. 5W PoE (802.3af)：36 V to 57 V, 0.17 A to 0.11 A, max. 6W
Working Temperature/Humidity	Temperature: -20°C to 50°C (-4°F to 122°F) Humidity: 95% or less
Protection Level	IP40
Dimensions	130mm102mm75mm
Mount	Corner Mount

Alarm Output	1, alarm output (alarm response actions configurable)
Alarm Action	SD recording/Relay output/Smart capture/FTP upload
Audio Input	Built-In Mic
Audio Output	Built-In Speaker
Communication Interface	1, RS-485 interface (half duplex)
Reset Key	1 reset button built in the motherboard

Image Sensor	Vanadium Oxide Uncooled Focal Plane Arrays
Resolution	160 × 120
Pixel Pitch	12 μm
Spectral Range	8 μm to 14 μm
NETD	< 50 mK (25°C, F#=1.1)
Focal Length	1.3 mm
Field of View	90.0° (H)x65.2° (V)
Min. Focusing Distance	0.01 m
Aperture	F1.0

EMC

EN55032
