Hikvision
0,00 ₼
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| API | ISAPI, RS-485, HTTP |
| Simultaneous Live View | Up to 6 channels |
| User/Host | Up to 32 users 3 levels: Administrator, Operator and User |
| Client | iVMS-4200 |
| Web Browser | IE8+, Chrome31-44, Firefox 30.0 - 51 |
| Alarm Trigger | Video tampering, alarm input, alarm output, network disconnected, IP address conflict, illegal login |
| General Function | Anti-flicker, heartbeat, password protection, watermark, email data report |
| Power Supply | 12 VDC ± 25%, terminal block PoE (802.3af, class 3) |
| Power Consumption and Current | 12 VDC, max. 7 W, 0.6A PoE(802.3af, 36 V to 57 V), max. 7 W, 0.2 A to 0.13 A |
| Material | Body: metal; enclosure: plastic |
| Dimensions | Camera: 226 × 88 × 64 mm (8.88″ × 3.48″ × 2.50″) Package: 260 × 125 × 125 mm (10.24″ × 4.92″ × 4.92″) |
| Operating Conditions | -30°C to +60°C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Protection Level | IP66 |
| Image Sensor | 1/3″ Progressive Scan CMOS |
| Shutter Speed | 1/25 s to 1/10,000 s |
| Angle Adjustment | Tilt: 0° to 45° |
| Digital Noise Reduction | 3D DNR |
| Auto-iris | Manual |
| Aperture | 2.8 mm: F2.0 4 mm: F2.2 |
| FOV | 2.8 mm: horizontal FOV 83°, vertical FOV 68° 4 mm: horizontal FOV 63°, vertical FOV 55° |
| Lens Mount | M12 |
| Focal length | 2.8 mm and 4 mm, optional |
| Image Enhancement | 3D DNR |
| Image Setting | Brightness and sharpness are adjustable by client software or web browser |
| Day/Night Switch | Auto, scheduled, day, and night |
| Max. Resolution | 640 × 960 |
| Main StreamMax. Frame Rate | 50Hz: 25fps (640 × 480) 60Hz: 24fps (640 × 480) |
| Sub-streamMax. Frame Rate | 50Hz: 25fps (640 × 960) 60Hz: 24fps (640 × 960) |
| Communication Interface | 1 RJ45 10M/100M Ethernet port 1 RS-485 interface |
| Alarm | 2 inputs, 1 output (up to 24 VDC 1 A, or 110 VAC 500 mA) |
| H.264 Compression Type | Baseline Profile/Main Profile/High Profile |
| Video Compression | Main stream: H.264 Sub-stream: H.264 |
| Video Bitrate | 32 Kbps to 8 Mbps |
| IR Range | Up to 5 m |
