| API | Open Network Video Interface, ISAPI, SDK, ISUP |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local service: Chrome 41.0+, Firefox 30.0+ |
| Linkage Method | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture |
| Online Upgrade | Yes |
| Firmware Version | V5.5.150 |
| General Function | Anti-flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter |
| Software Reset | Yes |
| Storage Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Power Supply | 24 VAC ± 20% |
| Power Consumption and Current | 24 VAC, 2.7 A, max. 40 W |
| Power Interface | 2-core terminal block |
| Camera Material | Metal & Plastic |
| Camera Dimension | 395 × 167 × 153 mm (15.55" × 6.57" × 6.02") |
| Package Dimension | 518 × 356 × 260 mm (20.39" × 14.01" × 10.23") |
| Camera Weight | 4250 g (9.37 lb.) |
| With Package Weight | 8200 g (18.08 lb.) |
| Image Sensor | Channel 1: 1/1.8" Progressive Scan CMOS Channel 2: 1/1.8 Progressive Scan CMOS" |
| Min. Illumination | Channel 1: Color: 0.002 Lux @(F1.4, AGC ON), B/W: 0.0006 Lux @(F1.4, AGC ON), 0 Lux with IR Channel 2: Color: 0.001 Lux @(F1.0, AGC ON) B/W: 0.0003 Lux @(F1.0, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/25 s~1/100,000 s |
| Slow Shutter | Yes |
| P/N | P/N |
| Wide Dynamic Range | 120 dB |
| Day & Night | Channel 1: IR cut filter Channel 2: No |
| Available Camera/Video Channel | 2 |
| Focus | Semi-auto, manual |
| Lens Type & FOV | Channel 1: 11~40 mm @F1.4, horizontal FOV: 37.0°~11.5°, vertical FOV: 20.2°~6.5°, diagonal FOV: 43.2°~13.2° Channel 2: 4 mm @F1.0, horizontal FOV: 89°, vertical FOV: 46.5°, diagonal FOV: 105° |
| Lens Mount | Channel 1: CS Channel 2: M16 |
| Aperture Type | Channel 1: P-Iris Channel 2: No |
| Wavelength | 750 nm |
| Supplement Light Range | Channel 1: hybrid illumination (750+whitelight) Face: 20 m, normal surveillance: 80 m Channel 2: warm lamp Normal surveillance: 30 m |
| Max. Resolution | Channel 1: 2560 × 1440 Channel 2: 2560 × 1440 |
| Main Stream | Channel 1: 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) Channel 2: 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream | Channel 1: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) Channel 2: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third Stream | Channel 1: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) Channel 2: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth Stream | Channel 1: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) Channel 2: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fifth Stream | Channel 1: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) Channel 2: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Video Compression | H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps~16 Mbps |
| H.264 Type | BaseLine Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.265 and H.264 support |
| Region of Interest (ROI) | 4 fixed regions for each stream |
| Smart IR | The IR LEDs on camera should support Smart IR function to automatically adjust power to avoid image overexposure. |
| Day/Night Switch | Day, Night, Auto, Schedule, Triggered by Alarm In |
| Target Cropping | Yes |
| DNR | 3D DNR |
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Image Enhancement | BLC, HLC, 3D DNR, Defog, EIS |
| Image Parameters Switch | Yes |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Alarm | 3 inputs, 2 outputs (max. 24 VAC or 24 VDC, 1 A) |
| Audio | 2 inputs (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 600 Ω, interface type: non-equilibrium, 2 built-in mics, 1 built-in speaker |
| RS-485 | 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Video Output | 1 Vp-p Composite Output (For debugging only) |
| On-board Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset | Yes |
| Communication Interface | 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| Power Output | 12 VDC, max. 200 mA (supported by all power supply types) |
| Heater | Yes |
| Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, scene change detection, audio exception detection, defocus detection |
| Counting | Yes |
| Class | Class A |
| Protection | IP66 |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate | 64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32~192 Kbps(MP2L2) |
| Audio Type | Mono sound |
| Multi-target-type Detection | Supports simultaneous detection of human body and face Gets 8 face features and 13 human body features |
| Face Capture | Face detection performance: detects up to 120 faces simultaneously Face detection angle: swings left and right from -60° to 60°, tilt up and down from -30° to 30° Upload face with background (1080p/720p) and closed-up face pictures |
| Face Recognition | Detects, captures and selects best human face pictures Recognizes face identity via face modeling, grading and comparing to those in face library Up to 10 face libraries, up to 150000 faces, and each face library is configurable Face library encryption: the camera chip has a hardware encryption module to protect data |
| Basic Event | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Solid Red | Yes |
