iDS-2CD8C46G0P-XZS

TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP,

PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS

microSD/SDHC/SDXC card (256 G) local storage, and NAS (NFS, SMB/CIFS), auto

network replenishment (ANR)

Plug-in required live view: IE8+

Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+

Local service: Chrome 41.0+, Firefox 30.0+

Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm

output, trigger recording, trigger capture

Anti- flicker, 5 streams and up to 5 custom streams, heartbeat, mirror, privacy

masks,flash log, password reset via e-mail, pixel counter

Channel 1: 1/1.8" Progressive Scan CMOS

Channel 2: 1/1.8 Progressive Scan CMOS

Channel 1:

Color: 0.0014 Lux @(F1.2, AGC ON)

B/W: 0.0004 Lux @(F1.2, AGC ON), 0 Lux with IR

Channel 2:

Color: 0.001 Lux @(F1.0, AGC ON)

B/W: 0.0003 Lux @(F1.0, AGC ON), 0 Lux with IR

Channel 1: 120 dB

Channel 2: digital WDR

Channel 1: IR cut filter

Channel 2: No

Channel 1: Capture unit: Tilt ±5° motorized ajdustment

Channel 2: Monitoring unit: Tilt ±15° motorized adjustment

Channel 1:

(Motorized) 10~50 mm: semi-auto

Channel 2:

(Fixed) 4 mm: No

Channel 1:

(Motorized) 10~50 mm @F1.2, horizontal FOV: 39.9°~9.5°, vertical FOV: 22.0°~5.3°, diagonal FOV: 46.3°~10.9°

Channel 2:

(Fixed) 4 mm @F1.0: horizontal FOV 160°, vertical FOV: 48°

Channel 1: (motorzied) 10~50 mm, F1.2

Channel 2: (Fixed) 4 mm, F1.0

Channel 1: (Mortorized) 10~50 mm, CS

Channel 2: (Fixed) 4 mm, M16

Channel 1: (Mortorized) 10~50 mm, Yes

Channel 2: (Fixed) 4 mm, No

Channel 1: (Mortorized) 10~50 mm, auto-iris

Channel 2: (Fixed) 4 mm, fixed

Channel 1: hybrid illumination

Channel 2: whitelight

Channel 1: 15 m (Face capture/recognition)

Channel 2: 30 m (normal surveillance)

Channel 1: 2560 × 1440

Channel 2: 4976 × 1452

Channel 1:

50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

Channel 2:

50Hz: 25 fps (4976 × 1452)

60Hz: 30 fps (4976 × 1452)

Channel 1:

50Hz: 25 fps (704 × 576, 640 × 480)

60Hz: 30 fps (704 × 480, 640 × 480)

Channel 2:

50Hz: 25 fps (2560 × 748)

60Hz: 30 fps (2560 × 748)

Channel 1:

50Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)

60Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)

Channel 2:

No

Channel 1:

50Hz: 25 fps (704 × 576, 640 × 480)

60Hz: 30 fps (704 × 480, 640 × 480)

Channel 2:

No

Channel 1:

50Hz: 25 fps (704 × 576, 640 × 480)

60Hz: 30 fps (704 × 480, 640 × 480)

Channel 2:

No

Channel 1: Yes

Channel 2: No

Channel 1: BLC, HLC, 3D DNR, Defog, EIS

Channel 2: BLC, HLC, 3D DNR, Defog

Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance

adjustable by client software or web browser

1 inputs (line in), 3.5 mm connector, max. input amplitude: 3.3 vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium;

1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 vpp, output impedance: 600 Ω, interface type: non-equilibrium,

64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/32Kbps(PCM)/8-

320Kbps(MP3)

Supports simultaneous detection of human body and face

Gets 8 face features and 13 human body features

Face detection performance: Detects up to 120 faces simultaneously

Face detection angle: Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°

Upload face with background (1920 × 1080, 1280 × 720, 2560 × 1440) and closed-up face pictures

Detects, captures and selects best human face pictures

Recognizes face identity via face modeling, grading and comparing to those in face library

Up to 10 face libraries, up to 150000 faces, and each face library is configurable

Face library encryption: the camera chip has a hardware encryption module to protect data

Motion detection, video tampering alarm, exception (network disconnected, IP

address conflict, illegal login, HDD full, HDD error)
