| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7, KC: KN32: 2015, KN35: 2015 |
| Təhlükəsizlik | CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005, LOA: IEC/EN 60950-1 |
| Ətraf Mühit | CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Mühafizə | IP67: IEC 60529-2013 |
| Korroziyadan Mühafizə | -Y: NEMA 4X (NEMA 250-2018) |
| Digər | PVC FREE |
| Audio Növü | Mono səs |
| Audio Sıxılması | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Sürəti | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 48 Kbps (PCM)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Nümunə Götürmə Sürəti | 8 kHz/16 kHz/32 kHz/48 kHz |
| Ətraf Mühit Səs Filtrasiyası | Bəli |
| Görüntü Sensoru | Channel 1: 1/1.2" Progressive Scan CMOS, Channel 2: 1/1.8 Progressive Scan CMOS, Channel 3: 1/1.2 Progressive Scan CMOS, Channel 4: 1/1.8 Progressive Scan CMOS" |
| Maks. Həlletmə | Channel 1: 3840 × 2160, Channel 2: 2560 × 1440, Channel 3: 3840 × 2160, Channel 4: 2560 × 1440 |
| Min. İşıqlandırma | Channel 1: Color: 0.0005 Lux @ (F1.2, AGC ON), 0 Lux with Light B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR Channel 2: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with IR Channel 3: Color: 0.0005 Lux @ (F1.2, AGC ON), 0 Lux with Light B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR Channel 4: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light B/W: 0.0001 Lux @ (F1.0, AGC ON), 0 Lux with IR |
| Örtük Vaxtı | 1 s to 1/100,000 s |
| Gündüz & Gecə | Channel 1: IR cut filter, Blue glass module to reduce ghost phenomenon, Channel 2: IR cut filter, Blue glass module to reduce ghost phenomenon, Channel 3: IR cut filter, Blue glass module to reduce ghost phenomenon, Channel 4: IR cut filter, Blue glass module to reduce ghost phenomenon |
| Bucaq Tənzimlənməsi | Channel 1: Pan: -10° to 190°, tilt: -5° to 25°, Channel 2: Pan: 0° to 180°, tilt: -5° to 25°, Channel 3: Pan: -10° to 190°, tilt: -5° to 25°, Channel 4: Pan: 0° to 180°, tilt: -5° to 25° |
| DORI | Fixed lens: D: 72.1 m, O: 28.6 m, R: 14.4 m, I: 7.2 m Varifocal lens: Wide: D: 150.3 m, O: 59.7 m, R: 30.1 m, I: 15 m Tele: D: 662.1 m, O: 262.7 m, R: 132.4 m, I: 66.2 m |
| Perimetr Mühafizəsi | Line crossing, intrusion, region entrance, region exiting Support alarm triggering by specified target types (human and vehicle) |
| Çoxlu Hədəf Növü Aşkarlanması | Detects up to 30 targets simultaneously,Supports simultaneous detection and capture of human body, face and vehicle, Gets 7 face features, Gets 13 human body features, Gets 2 vehicle features |
| Üz Tutma | Detects up to 120 faces simultaneously, Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°, Uploads face with background and closed-up face pictures |
| Üz Müqayisəsi | Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total, Supports face library encryption, Only channel 1/3 supports |
| Metadata | Intrusion detection,line crossing detection,region entrance detection,region exiting detection,face capture,multi-target-type detection |
| Əsas Hadisə | Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error, abnormal restart),alarm input and output,video quality diagnosis,vibration detection |
| Ağıllı Hadisə | Unattended baggage detection, object removal detection,scene change detection,audio exception detection,defocus detection |
| Əlaqələndirmə | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning,white light flashing |
| Qidalanma | 36 VDC ± 20%, 1.56 A, max. 56.12 W,two-core terminal block |
| Material | Plastics and metal |
| Ölçülər | 385.2 mm × 193.6 mm × 262.5 mm (15.2" × 7.6" × 10.3") |
| Qablaşdırma Ölçüləri | 490 mm × 280 mm × 343 mm (19.3" × 11" × 13.5") |
| Qablaşdırma ilə Çəki | Approx. 8835 g (19.5 lb.) |
| Saxlama Şərtləri | -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| İşə Salma və İstismar Şərtləri | -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Dil | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Ümumi Funksiya | Heartbeat,mirror,flash log,password reset via email,pixel counter,password protection,one-key reset,anti-banding |
| Isıtıcı | Bəli |
| Silgəc | Bəli |
| Buxar Aradan Qaldırma | Bəli |
| Yanıb-Sönən İşıq | Ağ İşıq |
| Əlavə İşıq Növü | IR,White Light,Hybrid (IR and White Light) |
| Əlavə İşıq Mənzili | Channel 1/3: up to 100 m Channel 2/4: up to 30 m |
| Supplement Light Number | 10 |
| Ağıllı Əlavə İşıq | Bəli |
| İQ Dalğa Uzunluğu | 850 nm |
| Görüntü Parametrlərinin Keçidi | Bəli |
| Görüntü Parametrləri | Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,AGC,adjustable by client software or web browser |
| Gündüz/Gecə Keçidi | Gündüz, Gecə, Avto, Cədvəl, Həyəcan Siqnalı |
| Geniş Dinamik Diapazon (WDR) | 140 dB |
| Görüntü Yaxşılaşdırması | BLC,HLC,3D DNR,Distortion Correction |
| Məxfilik Maskası | 8 programmable polygon privacy masks |
| Şəkil Üst-üstə Qoyma | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
| Ethernet İnterfeysi | 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| Daxili Yaddaş | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Daxili Mikrofon | Yes, 2 built-in microphones |
| Daxili Dinamik | Yes, 1 built-in speaker,Max. power consumption: 3 W, max. sound pressure level: 10 cm: 95 dB. |
| Audio | 2 inputs (line in), 1 output (line out), 3.5 mm connector, 2 channels |
| Həyəcan Siqnalı | 3 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A) |
| RS-485 | 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Sıfırlama Düyməsi | Bəli |
| Güc Çıxışı | 12 VDC, max. 100 mA |
| Linza Növü | Channel 1: Varifocal lens, 10 to 50 mm, Channel 2: Fixed focal lens, 4 mm, Channel 3: Varifocal lens, 10 to 50 mm, Channel 4: Fixed focal lens, 4 mm |
| Fokus Məsafəsi & Görüş Sahəsi | Channel 1: 10 to 50 mm, horizontal FOV 36.1° to 13.1°, vertical FOV 20.3° to 7.3°, diagonal FOV 41.8° to 14.9° Channel 2: 4 mm, horizontal FOV 85.2°, vertical FOV 45.2°, diagonal FOV 101.7° Channel 3: 10 to 50 mm, horizontal FOV 36.1° to 13.1°, vertical FOV 20.3° to 7.3°, diagonal FOV 41.8° to 14.9° Channel 4: 4 mm, horizontal FOV 85.2°, vertical FOV 45.2°, diagonal FOV 101.7° |
| Fokus | Avto, Yarı-avto, Əl ilə |
| Min. Focus Distance | Channel 1/3: 1.5 m Channel 2/4: 3 m |
| Diyafram Növü | DC diyafram |
| Diyafram Açıqlığı | Channel 1: F1.6, Channel 2: F1.0, Channel 3: F1.6, Channel 4: F1.0 |
| Fokus Dərinliyi | Channel 1: 3.1 m to ∞ Channel 2: 3.1 m to ∞ Channel 3: 3.1 m to ∞ Channel 4: 3.1 m to ∞ |
| Protokollar | TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ISUP, ARP, WebSocket, WebSockets |
| Eyni Anda Canlı Baxış | Up to 20 channels |
| API | ONVIF (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP |
| İstifadəçi/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Təhlükəsizlik | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),CVR,NVR, Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Müştəri | iVMS-4200,Hik-Connect |
| Veb Brauzer | Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 13+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Hərəkət Diapazonu (Pan) | Channel 1/Channel 3: Pan: -10° to 190° Channel 2/Channel 4: Pan: 0° to 180° |
| Hərəkət Diapazonu (Tilt) | Channel 1/Channel 3: Tilt: -5° to 25° Channel 2/Channel 4: Tilt: -5° to 25° |
| Pan Sürəti | Pan speed: configurable from 0.1° to 5°/s, preset speed: 2.5°/s |
| Tilt Sürəti | Tilt speed: configurable from 0.1° to 5°/s, preset speed 2.5°/s |
| Peyk Mövqeləndirmə Aşkarlanması | GPS |
| Əsas Axın | Channel 1 & Channel 3: 50 Hz: 25 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) Channel 2 & Channel 4: 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Alt Axın | Channel 1 & Channel 3: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) Channel 2 & Channel 4: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Üçüncü Axın | Channel 1 & Channel 3: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) Channel 2 & Channel 4: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Dördüncü Axın | Channel 1 & Channel 3: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) Channel 2 & Channel 4: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Beşinci Axın | Channel 1 & Channel 3: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) Channel 2 & Channel 4: 50 Hz: 25 fps (704 × 576, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Video Sıxılması | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, Fifth stream: H.265/H.264/MJPEG |
| Video Bit Sürəti | Channel1/3: 32 Kbps to 16 Mbps, Channel2/4: 32 Kbps to 8 Mbps |
| H.264 Növü | Baseline Profile,High Profile,Main Profile |
| H.265 Növü | Main Profile |
| Bit Sürəti Nəzarəti | CBR, VBR |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | H.264 and H.265 encoding |
| Maraq Bölgəsi (ROI) | 4 fixed regions for each stream |
| Hədəf Kəsmə | Bəli |
