Hikvision
0,00 ₼
| Protocols | TCP/IP, HTTP, HTTPS, FTP, DNS, RTP, RTSP, RTCP, NTP, IPv6, UDP |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Version 2.1, PROFILE S, PROFILE G), ISAPI, SDK |
| User/Host | Up to 32 users 3 user levels: administrator, operator, and user |
| Security | Password protection, HTTPS encryption, digest authentication for HTTP/HTTPS, digest authentication for ONVIF (Version 2.1) |
| Network Storage | Micro SD/TF card (128 GB), local storage and CVR, NVR, ANR |
| Client | iVMS-8600, iVMS-4200 (Only for video live view and LPR information search), Hik-Central Master, Hik-Central Pro |
| Web Browser | IE8-IE11, plug-in free live view supported |
| Firmware Version | V4.3.1 |
| Operating System | Linux |
| Power | 12 VDC ± 10%; 10 W |
| Material | Aluminum alloy |
| Dimension | With package: 79 × 69 × 161.17 mm (3.11" × 2.72" × 6.35") |
| Weight | 0.98 ± 0.1 kg (2.16 ± 0.22 lb) |
| Operating Condition | Temperature: -40 °C to 60 °C (-40 °F to 140 °F) Humidity: 95% or less (non-condensing) |
| General Function | One-key reset, three streams, heartbeat, password protection, watermark |
| Heater | Supported |
| Image Sensor | 5 MP (2/3'' GMOS) |
| Max. Resolution | 2464 × 2056 |
| Min. Illumination | Color: 0.001 Lux@(F1.4, AGC ON), 0.0005 Lux with IR |
| Shutter Time | 50 μs to 20,000 μs |
| Day & Night | IR cut filter |
| Focal Length & FOV | 15 to 50 mm |
| Focus | Manual |
| Aperture | F1.4-C |
| External Supplement Light | External strobe/flash/solid light |
| Main Stream | 50 Hz: 50 fps (2448 × 2048, 2464 × 2056, 2048× 1536, 1920 × 1080) 60 Hz: 30 fps(2448 × 2048, 2464 × 2056, 2048× 1536, 1920 × 1080) |
| Sub Stream | 1920 × 1080, 1280 × 720, 704 × 576, 352 ×288 |
| Video Compression | Main stream: H.265/H.264/MJPEG Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline profile/Main profile/High profile |
| H.265 Type | Baseline profile/Main profile/High profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or webbrowser. |
| Day/Night Switch | Auto/Scheduled/Triggered by alarm in |
| SNR | 60 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
| Picture Overlay | Logo picture can be overlaid on video with 128 × 128 24-bit bmp format. |
| Ethernet Interface | 2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet interfaces |
| On-board Storage | Built-in micro SD/TF card, up to 128 GB |
| Alarm | 2 input interfaces (T1, SYNC), 7 output interfaces |
| RS-485 | 3 RS-485 interfaces (half duplex, HIKVISION) |
| RS-232 | 1 RS-232 interface |
| USB | 1 USB 2.0 interface |
| Basic Event | HDD error, network disconnected, IP address conflicted, vehicle detector exception, traffic light detector exception |
| EMC | CE, FCC |
| Environment | RoHS |
| Coverage | Up to 2 lanes |
| Trigger Mode | External I/O trigger/Radar trigger/Video trigger |
| Smart Function | License plate recognition Vehicle type classification, vehicle color recognition, no-plate vehicle capture, moving direction detection |
| LPR Countries/Regions | Middle East: The United Arab Emirates (Abu Dhabi, Ajman, Dubai, Fujairah, Ras Al Khaimah, Sharjah and Umm Al Quwain), Qatar, Iran, Iraq, Egypt, Jordan, Kuwait, Saudi Arabia, Pakistan, Oman, Lebanon, Bahrain Africa: Nigeria, Kenya, Ivory Coast , South Africa, Tanzania, Mauritius, Morocco, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Senegal, Algeria Asia-Pacific: Australia, New Zealand, Indonesia, Malaysia, Singapore, South Korea, Thailand, Vietnam, the Philippines, Hong Kong, Macao, Taiwan, Burma, India, Mongolia, Cambodia, Laos, Bangladesh America: The United States of America, Canada, Argentina, Chile, Paraguay, Uruguay, El Salvador, Bolivia, Colombia, Brazil, Ecuador, Peru, Mexico, Panama, Costa Rica, Trinidad and Tobago, the Dominican Republic, Guatemala Europe: Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, the Republic of North Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, the UK, Ireland, Germany, Italy, Austria, Israel, Palestinian State, Belgium, Luxembourg, Albania, Kosovo Russian-Speaking Regions: Azerbaijan, Belarus, Kazakhstan, Lithuania, Georgia, Estonia, Latvia, Russia, Ukraine, Moldova, Uzbekistan, Kyrgyzstan, Armenia |
| Accuracy (Under recommended installation and lighting conditions) | Capture rate > 98% Vehicle moving direction recognition accuracy > 98.5% LPR accuracy > 98% Mistaken capture rate < 2% European and Russian-Speaking Regions: LPR accuracy > 98% Country/Region recognition accuracy > 95% |
| No License Plate Detection | Supported |
| Motorcycle LPR | Supported |
| Vehicle Type | Car/Van/Bus/Truck/Light Truck/SUV_MPV/Pickup/Pedestrian/Motorcycle/Tricycle |
| Vehicle Color | Red, yellow, green, blue, pink, purple, cyan, brown, white, grey, black Recognizable at daytime only. |
| Vehicle Manufacturer | 84 manufacturers: Hyundai, Toyota, KIA, Honda, Volkswagen, Benz, Nissan, Ford, Isuzu,BMW, Chevrolet, Mitsubishi, Renault, Opel, Suzuki, Skoda, Daewoo, Audi, Mazda, GAC HINO,Peugeot, SsangYong, Citroen, Fiat, Scania, MAN, Volvo, Lexus, Seat, Land Rover, Daihatsu,Dongwo, Subaru, Iveco, MINI, JEEP, Porsche, Chery, Dodge, Chrysler, Acura, Alfa Romeo,Great Wall, Infiniti, Smart, Saic Maxus, JAC, Jaguar, GMC, Lincoln, JMC, SAAB, FAW, Yutong,Guangzhou Yunbao, Joylong, Geely, Cadillac, JBC, An‘kai, Haima, Foton, King Long, Dongfeng,Geely-Emgrand, Perodua, UD, BYD, Renault Samsung, Proton,HICOM,Malaysia_Unknown 1,Hyundai-Rohens, SsangYong-Old Version, Equus-Old Version, CNHTC, Rolls-Royce, BeibenTruck, Haval, Hino, Kia-Borrego, Chang‘an, Alfa, FORO |
| License Plate Color Recognition | Customized to support |
| Driving on Lane Line Detection | Supported (only in strobe light mode) |
| Illegal Lane Change Detection | Supported (only in strobe light mode) |
| Wrong-way Driving Detection | Supported |
| Emergency Lane Occupation | Supported (truck forbidden lane, emergency lane, urban bus lane) |
| Seatbelt Detection | Supported (with flash supplement light) |
| Phone Call Detection | Supported (with flash supplement light) |
| Speed Range | 5 to 250 km/h |
