| Protocol | HTTPS, RTSP, NTP, FTP |
| API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK, ISUP |
| Operating Condition | -20 °C to 60 °C (-4 °F to 140 °F), Humidity 95% or less (non-condensing) |
| Operating System | Linux |
| Storage Condition | -30 °C to 70 °C (-22 °F to 158 °F). Humidity 95% or less (non-condensing) |
| MIC | Supported |
| Speaker | 1 Built-in speaker, Max. power consumption: 1.2 W, Max. sound pressure level: 95 dB (10 cm) |
| Client | Hik-Connect, HikCentral Pro, HikCentral Master |
| Web Browser | Plug-in required live view: IE 10+Plug-in free live view: Chrome 57.0+, Firefox 52.0+Local service: Chrome 57.0+, Firefox 52.0+ |
| Dimension | 462.02 mm × 355.60 mm × 175.0 mm (18.19" × 14.0" × 6.89") |
| Power | 5 VDC, 2.0 A, max. 10 W |
| Installation Method | Desk-Mounted, Wall-Mounted, Tripod-Mounted, Movable Bracket |
| Packing List | 1 × wall mounted bracket |
| Image Sensor | 1/2.9" progressive scan CMOS |
| Zoom | 4x Digital |
| Max. Resolution | 1920 × 1080 |
| Min. Illumination | Color: 0.015 Lux@ (F1.0, AGC ON) |
| Day & Night | Switch IR Cut Filter Automatically |
| Focal Length | 3.8 mm fixed lens |
| Aperture | F2.0 |
| FOV | Horizontal FOV: 80° Vertical FOV: 44° Diagonal FOV: 98° |
| Video Compression | H.264, H.265 |
| Video Format | PS |
| Main Stream | 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 704 × 288, 352 × 288) |
| Sub-Stream | 25 fps (1280 × 720, 704 × 576, 704 × 288, 352 × 288) |
| Image Format | JPEG |
| Indicator | 1 Indicator for Charging/Working/Recording/Exception |
| Button | Power |
| SIM Card | Available for models with '/GLE', '/GLE/PIR': 1 (Nano-SIM card slot) |
| Ethernet | 1 RJ45 10M/100M/1000M self-adaptive ethernet port(s) |
| Charging Interface | Type-C |
| Extended Storage | 1 Built-in memory card slot, up to 512 GB, supporting TF card |
| USB | USB 2.0 |
| Audio | 1 built-in mic(s),1 speaker(s) |
| General | RJ45 port, USB port |
| RF | EN 300 328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G); EN 55032:2015; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 50130-4:2011 +A1:2014); |
| EMC | CE-EMC: EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014 |
| Safety | CB: IEC 62368-1: 2014+A11, IEC 62368-1: 2018 CE-LVD: EN 62368-1: 2014/A11: 2017, EN IEC 62368-1:2020+A11:2020 CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment | CE-RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Protection | Available for model with '/GLE/PIR': IP66, Available for model with '/GLE': not supported |
| Audio Compression | G.711ulaw, G.711alaw, G.722.1 |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw), 16 Kbps (G.722.1) |
| IR Range | Up to 10 m |
| IR Wavelength | 850 nm |
| Battery Type | Lithium-ion battery, integral |
| Capacity | 3220 mAh |
| Charging Time | ≤ 4 h |
| Battery Life | Up to 12 h in 720p resolution¹ |
| Pan | 0°~355° |
| Tilt | -2.5° to 42.5° (Auto-flip) |
| RAM | 128MB |
| ROM | Default 64 GB, 128 GB/256/512 GB optional |
| Screen Type | LCD |
| Touchscreen | Not supported |
| Resolution | 128x64 |
| Screen Size | 0.96" |
| Positioning Mode | GPS |
| Wi-Fi Frequency Band | 2.412 to 2.472 GHz |
| Cellular Network | Available for models with '/GLE', '/GLE/PIR': GSM: 850/900/1800/1900 WCDMA: B1/B8 FDD -LTE: B1/B3/B5/B7/B8/B20 TDD -LTE: B38/B40/B41 |
| Wi-Fi Protocol | 802.11 a/b/g/n |
