| CPU | Intel®, Xeon®, Quad-Core (64-bit) E3-1225 V5 CPU @,3.30GHz, |
| Memory | 4 × DDR4 slots, 8GB ECC + UDIMM memory (extendable,up to 64 GB) |
| Operating system | Microsoft®, Windows 10 (pre-installed with HikCentral,V1.1),Optional:Microsoft®, Windows Server 2012 R2 (preinstalled,with HikCentral V1.1) |
| System disk | Industrial-level SSD with 128 GB capacity |
| HDD Slot | 4 × SATA interfaces, 2.5-inch HDDs are connectable |
| HDD for HikCentral | 1 × 2.5-inch HDD of 1 TB are delivered with device,Expandable to up to four 2.5-inch HDDs |
| Audio Input | 1, RCA (2.0 Vp-p, 1KΩ) |
| Audio Output | 1, RCA (2.0 Vp-p, 1KΩ) |
| Network Interface | 4 RJ-45 10/100/1000 Mbps self-adaptive Ethernet,interfaces, independent IP address by default, |
| Incoming | 500 Mbps |
| Outgoing | 400 Mbps |
| Default License | License of max. 128 cameras |
| Maximum License | Expandable to License of up to 1,024 cameras |
| Number of Clients (Control Client or Web Client) Concurrently | Maximum 100 |
| Number of Mobile Clients Concurrently | Maximum 100 |
| Number of Connected Encoding Devices | Maximum 256 |
| Number of Connected Cameras | Maximum 256 |
| Number of Alarm Inputs | Maximum 256 |
| Number of Alarm Outputs | Maximum 256 |
| Number of ANPR Cameras | Maximum 20 |
| Number of Area Hierarchies | Maximum 5 |
| Number of Cameras per Area | Maximum 64 |
| Number of Alarm Inputs per Area | Maximum 64 |
| Number of Alarm Outputs per Area | Maximum 64 |
| Number of Maps | Maximum 1,024 |
| Resolution of Map | Maximum 1920 × 1080 |
| Number of Map Hierarchies | Maximum 6 |
| Number of Hot Regions per Map | Maximum 64 |
| Number of Camera Hot Spots per Map | Maximum 128 |
| Number of Alarm Input Hot Spots per Map | Maximum 128 |
| Number of Alarm Output Hot Spots per Map | Maximum 128 |
| Number of Labels per Map | Maximum 128 |
| Number of Hot Regions in Total | Maximum 1,024 |
| Number of Camera Hot Spots in Total | Maximum 3,000 |
| Number of Alarm Input Hot Spots in Total | Maximum 3,000 |
| Number of Alarm Output Hot Spots in Total | Maximum 3,000 |
| Number of Labels in Total | Maximum 3,000 |
| Number of Users | Maximum 3,000 |
| Number of Roles | Maximum 3,000 |
| Number of Alarm Logs | Maximum 60,000,000 |
| Number of Event Logs | Maximum 60,000,000 |
| Number of Operation Logs | Maximum 5,000,000 |
| Number of System Logs | Maximum 5,000,000 |
| Number of Tags | Maximum 60,000,000 |
| Number of People Counting Records | Maximum 5,000,000, stored for 2 years |
| Number of Heat Map Records | Maximum 250,000, stored for 2 years |
| Number of License Plate Recognition Records | Maximum 60,000,000 |
| Smart Wall Module on Control Client | Optional (not installed by default) |
| Remote Site Management (RSM) | Optional (not activated by default, based on the License) If activated maximum number of resources can be managed: 1,024 Remote Sites and 1,024 cameras |
| RoseReplicatorPlus Control Center | Optional (not installed by default) |
| Manageable Device Type | NVR, DVR, network camera, encoder, decoder, video wall controller, CVR, Cloud Storage Server, Blazer Express (version 1.4 and later, managed via RSM), Blazer Pro without RSM (version 2.1 and later, managed via RSM) |
| Language of Operating System and HikCentra | Bulgarian, Czech, Danish, English, French, German, Hungarian, Japanese, Polish, Portuguese, Russian,Simplified Chinese, Spanish, Thai, Traditional Chinese, and Turkish |
