| CPU | Intel®, Xeon®, Quad-Core (64-bit) E3-1225 V5 CPU @,3.30GHz, |
| Memory | 4 × DDR4 slots, 8GB ECC + UDIMM memory (extendable,up to 64 GB) |
| Operating system | Microsoft®, Windows 10 (pre-installed with HikCentral,V1.1),Optional:Microsoft®, Windows Server 2012 R2 (preinstalled,with HikCentral V1.1) |
| System disk | Industrial-level SSD with 128 GB capacity |
| HDD Slot | 4 × SATA interfaces, 2.5-inch HDDs are connectable |
| HDD for HikCentral | 1 × 2.5-inch HDD of 1 TB are delivered with device,Expandable to up to four 2.5-inch HDDs |
| Audio Input | 1, RCA (2.0 Vp-p, 1KΩ) |
| Audio Output | 1, RCA (2.0 Vp-p, 1KΩ) |
| Network Interface | 4 RJ-45 10/100/1000 Mbps self-adaptive Ethernet,interfaces, independent IP address by default, |
| Incoming | 500 Mbps |
| Outgoing | 400 Mbps |
| Default License | License of max. 256 cameras |
| Maximum License | Expandable to License of up to 1,024 cameras |
| Number of Clients (Control Client or Web Client) Concurrently | Maximum 100 |
| Number of Mobile Clients Concurrently | Maximum 100 |
| Number of Connected Encoding Devices | Maximum 256 |
| Number of Connected Cameras | Maximum 256 |
| Number of Alarm Inputs | Maximum 256 |
| Number of Alarm Outputs | Maximum 256 |
| Number of ANPR Cameras | Maximum 20 |
| Number of Area Hierarchies | Maximum 5 |
| Number of Cameras per Area | Maximum 64 |
| Number of Alarm Inputs per Area | Maximum 64 |
| Number of Alarm Outputs per Area | Maximum 64 |
| Number of Maps | Maximum 1,024 |
| Resolution of Map | Maximum 1920 × 1080 |
| Number of Map Hierarchies | Maximum 6 |
| Number of Hot Regions per Map | Maximum 64 |
| Number of Camera Hot Spots per Map | Maximum 128 |
| Number of Alarm Input Hot Spots per Map | Maximum 128 |
| Number of Alarm Output Hot Spots per Map | Maximum 128 |
| Number of Labels per Map | Maximum 128 |
| Number of Hot Regions in Total | Maximum 1,024 |
| Number of Camera Hot Spots in Total | Maximum 3,000 |
| Number of Alarm Input Hot Spots in Total | Maximum 3,000 |
| Number of Alarm Output Hot Spots in Total | Maximum 3,000 |
| Number of Labels in Total | Maximum 3,000 |
| Number of Users | Maximum 3,000 |
| Number of Roles | Maximum 3,000 |
| Number of Alarm Logs | Maximum 60,000,000 |
| Number of Event Logs | Maximum 60,000,000 |
| Number of Operation Logs | Maximum 5,000,000 |
| Number of System Logs | Maximum 5,000,000 |
| Number of Tags | Maximum 60,000,000 |
| Number of People Counting Records | Maximum 5,000,000, stored for 2 years |
| Number of Heat Map Records | Maximum 250,000, stored for 2 years |
| Number of License Plate Recognition Records | Maximum 60,000,000 |
| Smart Wall Module on Control Client | Optional (not installed by default) |
| Remote Site Management (RSM) | Optional (not activated by default, based on the License) If activated maximum number of resources can be managed: 1,024 Remote Sites and 1,024 cameras |
| RoseReplicatorPlus Control Center | Optional (not installed by default) |
| Manageable Device Type | NVR, DVR, network camera, encoder, decoder, video wall,controller, CVR, Cloud Storage Server, Blazer Express,(version 1.4 and later, managed via RSM), Blazer Pro,without RSM (version 2.1 and later, managed via RSM), |
| Language of Operating System and HikCentra | Bulgarian, Czech, Danish, English, French, German, Hungarian, Japanese, Polish, Portuguese, Russian,Simplified Chinese, Spanish, Thai, Traditional Chinese, and Turkish |
