| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021 RCM: AS/NZS CISPR 32: 2015, |
| Təhlükəsizlik | CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, LOA: IEC/EN 60950-1 |
| Ətraf Mühit | CE-ROHS (2011/65/EU); REACH (Regulation (EC) No 1907/2006); WEEE (2012/19/EU); |
| Mühafizə | IP66: IEC 60529-2013 |
| Korroziyadan Mühafizə | NEMA 4X (NEMA 250-2018) |
| Ətraf Mühit Səs Filtrasiyası | Bəli |
| Audio Nümunə Götürmə Sürəti | 8 kHz/16 kHz/32 kHz/48 kHz |
| Audio Sıxılması | G.722.1/MP2L2/G.726/G.711/MP3/PCM/AAC-LC |
| Audio Bit Sürəti | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/PCM/16 to 64 Kbps (AAC-LC) |
| Audio Növü | Mono səs |
| Görüntü Sensoru | 1.61ʺ Progressive Scan CMOS |
| Maks. Həlletmə | 6816 × 3840 |
| Min. İşıqlandırma | Color: 0.001 Lux @ (F1.2, AGC ON) Black: 0.0005 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Örtük Vaxtı | 1/25 s to 1/100,000 s |
| Gündüz & Gecə | IR cut filter. Blue glass module to reduce ghost phenomenon. |
| DORI | 85 mm: D (Detect) : 1172.4 m, O (Observe) : 465.2 m, R (Recognize) : 234.5 m, I (Identify) : 117.2 m; 50 mm: D (Detect) : 689.7 m, O (Observe) : 273.7 m, R (Recognize) : 137.9 m, I (Identify) : 69 m |
| İnsan Sıxlığı | Supports up to 8 detection regions, and independent arming schedule and linkage method People density detection: supports setting density levels based on the number of people and target pixel ratio Supports scheduled data uploading |
| Əlaqələndirmə | Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording |
| Qidalanma | 24 VAC ± 20%, 2.28 A, max. 37.4 W |
| Dil | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Ümumi Funksiya | One-key reset, anti-flicker, heartbeat, mirror, password protection, pixel counter |
| Saxlama Şərtləri | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| İşə Salma və İstismar Şərtləri | -40 °C to 60 °C (-40 °F to 140 °F), humidity 95% or less (non-condensing) |
| Material | Metal |
| Ölçülər | 569 mm × 171.5 mm × 165.8 mm (22.4" × 6.75" × 6.53") |
| Qablaşdırma Ölçüləri | 668 mm × 408 mm × 289 mm (26.3″ × 16.06″ × 11.38″) |
| Qablaşdırma ilə Çəki | Approx. 7.9 kg (17.42 lb.) |
| Əlavə İşıq Növü | IR |
| Əlavə İşıq Mənzili | Up to 100 m |
| İQ Dalğa Uzunluğu | 850 nm |
| Geniş Dinamik Diapazon (WDR) | Digital WDR |
| Şəkil Üst-üstə Qoyma | LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
| Gündüz/Gecə Keçidi | Night,Alarm Trigger,Day,Schedule,Auto |
| Görüntü Yaxşılaşdırması | HLC,3D DNR,EIS,BLC |
| Görüntü Parametrləri | contrast,saturation,white balance,brightness,gain,sharpness |
| Həyəcan Siqnalı | 3 inputs, 3 outputs (max. 24 VDC/VAC, 1 A) |
| Audio | 1 inputs (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium; 1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium; |
| Daxili Yaddaş | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB |
| Video Çıxışı | 1 Vp-p composite output (75 Ω/CVBS), only for adjustment |
| Sıfırlama Düyməsi | Bəli |
| Ethernet İnterfeysi | 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| Güc Çıxışı | 12 VDC, max. 100 mA |
| Fiber Optik | 1 fiber optical interface, SFP module, single mode, 20 km transmission distance, 1310 nm (TX) and 1550 nm (RX), 1250 Mbps transmission rate |
| Linza Növü | C/CS |
| Fokus Məsafəsi & Görüş Sahəsi | 50 mm, horizontal FOV 22.4°, vertical FOV 12.7°, diagonal FOV 25.7° 85 mm, horizontal FOV 13.3°, vertical FOV 7.5°, diagonal FOV 15.4° |
| Diyafram Açıqlığı | Max. F2.0 |
| Eyni Anda Canlı Baxış | Up to 20 channels |
| API | ONVIF (Profile S, Profile G),ISAPI,SDK,ISUP |
| Protokollar | SSL/TLS,IGMP,UPnP,WebSocket,SNMP,IPv4,DNS,Bonjour,UDP,WebSockets,RTSP,RTCP,DDNS,NTP,RTP,HTTP,ICMP,PPPoE,802.1X,DHCP,QoS,FTP,SMTP,HTTPS,SFTP,IPv6,TCP/IP |
| İstifadəçi/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| Təhlükəsizlik | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
| Şəbəkə Yaddaşı | NAS (NFS, SMB/CIFS) |
| Müştəri | iVMS-4200,HikCentral Professional |
| Veb Brauzer | Plug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Peyk Mövqeləndirmə Aşkarlanması | GPS |
| Əsas Axın | 1 encoder track mode: H.264/H.265: 50 Hz: 25 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592, 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592, 3840 × 2160, 3072 × 1728, 2560 × 1440, 1920 × 1080, 1280 × 720) 3 encoder tracks mode: H.264/H.265: 50 Hz: 25 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592) 60 Hz: 30 fps (6816 × 3840, 6048 × 4008, 5472 × 3648, 4944 × 3280, 4608 × 2592) |
| Alt Axın | 1 encoder track mode: H.264/H.265/MJPEG: 50 Hz: 25 fps (704 × 480, 640 × 480) 60 Hz: 30 fps (704 × 480, 640 × 480) 3 encoder tracks mode: No |
| Üçüncü Axın | 1 encoder track mode: H.264/H.265: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) 3 encoder tracks mode: No |
| Dördüncü Axın | 1 encoder track mode: H.264/H.265/MJPEG: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) 3 encoder tracks mode: No |
| Beşinci Axın | 1 encoder track mode: H.264/H.265/MJPEG: 50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) 3 encoder tracks mode: No |
| Video Sıxılması | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 Fourth stream: H.265/H.264/MJPEG Fifth stream: H.265/H.264/MJPEG |
| Video Bit Sürəti | 32 Kbps to 32 Mbps |
| H.264 Növü | Baseline Profile,Main Profile,High Profile |
| H.265 Növü | Main Profile |
| Miqyaslanabilən Video Kodlaşdırma (SVC) | Bəli |
| Maraq Bölgəsi (ROI) | 4 fixed regions for each stream |
| Hədəf Kəsmə | Bəli |
