SXTsq 5 AC

The SXTsq 5 ac is a compact and lightweight outdoor 5Ghz 802.11ac wireless device with an integrated antenna, perfect for point-to-point links or as a CPE unit. The device includes one 10/100/1000 Mbit Ethernet port to fully utilize speeds that 802.11ac protocol provides.

The SXTsq 5 ac retains a 16 dBi antenna like the SXT 5 ac, our previous model, yet the antenna design has been improved and the physical size has been dramatically reduced - the SXTsq is two times thinner.

The weatherproof enclosure includes slots for directly attaching a hose clamp mount in three different mounting

places, with ability to be mounted on horizontal railings.There is also an easily accessible grounding connection to

protect it against lightning.

The device can be mounted on horizontal and vertical poles and masts, but for precise alignment, separately available is the QuickMount Pro, which allows to adjust in every angle (see photo and related product).

Receiver sensitivity:

(5 GHz) Transmit power (dBm)           Receiver sensitivity

6MBit/s           25                -96

54MBit/s       21 -80

MCS0 25 -96

MCS7 20 -75

RBSXTsqG-5acD replaces the folowing EOL products: MikroTik SXT 5 ac RBSXTG-5HPacD; MikroTik SXT Lite5 ac RBSXT5HacD2n.
