| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| User/Host | Up to 32 users,3 levels: Administrator, Operator and User |
| Network Storage | microSD/SDHC/SDXC card (256 GB), local storage and ANR Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11 |
| Alarm Trigger | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Firmware Version | 5.5.93 |
| General Function | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter, flash log |
| Startup and Operating Conditions | -10 °C to 50 °C (14 °F to 122 °F), humidity 95% or less (non-condensing) |
| Power Supply | DC: 12 V ± 25% AC: 24 V ± 20% PoE (802.3af, class 3), two-core terminal block |
| Power Consumption and Current | DC: 12 V, 0.4 A, max. 4.8 W AC: 24 V, 0.2 A, max. 4.8 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 6 W |
| Camera Dimension | Camera: 68 × 56 × 143 mm (2.7" × 2.2"× 5.6") With package: 172 × 110 × 99 mm (6.8" × 4.3"× 3.9") |
| Camera Weight | Camera: approx. 450 g (1 lb.) With package: approx. 600 g (1.3 lb.) |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Min. Illumination | Color: 0.005 Lux @ (F1.2, AGC ON) |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | Digital WDR |
| Day & Night | IR Cut Filter |
| Lens Type | 2.7 to 10 mm, 2.7 to 13 mm and 5 to 50 mm optional |
| FOV | 2.7 to 10 mm: horizontal FOV: 105.8° to 35.1°, vertical FOV: 55.8° to 19.7°, diagonal FOV: 126.5° to 40.3° 2.7 to 13 mm: horizontal FOV: 106.5° to 26.4°, vertical FOV: 58.4° to 14.9°, diagonal FOV: 123.6° to 30.3° 5 to 50 mm: horizontal FOV: 55.2° to 6.4°, vertical FOV: 31.1° to 3.6°, diagonal FOV: 63.2° to 7.3° |
| Aperture | F1.6 |
| Lens Mount | CS mount |
| Auto-Iris | DC drive |
| Max. Resolution | 1920 × 1080 |
| Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream | 50Hz: 1fps (1280 × 720, 640 × 360) 60Hz: 1fps (1280 × 720, 640 × 360) |
| Video Compression | Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Day/Night Switch | Day/Night/Auto/Schedule/Triggered by alarm in |
| Target Cropping | No |
| DNR | 3D DNR |
| Image Enhancement | BLC/3D DNR/HLC |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Audio | 1 line in (3.5 mm), 1 line out (3.5 mm), 1 mic in, dual sound track |
| Alarm | 1 input, 1 output |
| Video Output | 1Vp-p composite output(75Ω/BNC) (For adjustment only) |
| On-board Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Hardware Reset | Reset via reset button on camera body, web browser and client software |
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Smart Event | Line crossing detection, 1 line configurable Intrusion detection, 1 region configurable |
| Face Detection | Yes |
| Exception Detection | Scene change detection |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
