Hikvision
0,00 ₼
| Network Storage | Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Alarm Trigger | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| General Function | One-key reset, anti-flicker, three streams, heartbeat, password protection, privacy mask, watermark, IP address filter |
| SIFIRLA | Yes |
| Startup and Operating Conditions | -30 °C – 60 °C (-22 °F – 140 °F), Humidity 95% or less (non-condensing) |
| Power Supply | 12 V DC ± 20%, PoE (802.3af, class 3),Terminal block for DC input |
| Power Consumption and Current | 12 V DC ± 20%: max. 9W/0.75A,PoE (802.3af): max. 10W/0.21A |
| Dimensions | Φ145.96 × 133.5 mm (Φ5.75″ × 5.26″) |
| Interface Protection | IP66, IK10 |
| Image Sensor | 1/1.8″ Progressive Scan CMOS |
| Min. Illumination | Color: 0.002 Lux @ (F1.2, AGC ON), 0.0027 Lux @ (F1.4, AGC ON), 0 Lux with IR,B/W: 0.0002 Lux @ (F1.2, AGC ON), 0.00027 Lux @ (F1.4, AGC ON), 0 Lux with IR" |
| Shutter Speed | 1 s - 1/100,000 s |
| Slow Shutter | Support |
| Day &Night | IR Cut Filter |
| Wide Dynamic Range | 120dB |
| DNR | 3D DNR |
| Axis Adjustment | Pan: 0° to 355°, tilt: 0° to 70°, rotate: 0° to 355° |
| Lens | 2.8 – 12 mm F1.4, horizontal angle of view 90.1° - 31° |
| Auto-Iris | DC drive |
| Lens Mount | Φ14 |
| IR Range | 10 m to 30 m |
| Max. Resolution | 1920 × 1080 |
| Main Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub Stream | 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240),60Hz: 30fps (704 × 480, 640 × 480, 352 × 240, 320 × 240) |
| Third Stream | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288, 320 × 240),60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240, 320 × 240) |
| Video Compression | Main stream: H.265/H.264,Sub stream: H.265/H.264/MJPEG,Third stream: H.265/H.264 |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Video Bit Rate | 32 Kbps – 16 Mbps |
| Image Enhancement | BLC/HLC/3D DNR/Defog/EIS |
| Image Setting | Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser |
| Target Cropping | Support |
| Day/Night Switch | Auto/Schedule/Triggered by Alarm In (-S) |
| Picture Overlay | LOGO picture can be overlaid on video with 128 × 128 24bit bmp format |
| Communication Interface | 1 RJ45 10M/100M Ethernet port, with –S model: 1 RS-485 interface |
| Audio | With –S model: 1 input (line in), 1 output, dual-track |
| Alarm | With –S model: 2 inputs, 2 outputs (up to DC24V 1A or AC110V 500mA ) |
| Video Output | 1Vp-p composite output (75 Ω/BNC) |
| On-board Storage | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| H.264+ | Support |
| H.265+ | Support |
| Face Detection | Human face appears in the image can be detected and trigger linkage method |
| Exception Detection | Scene change detection |
| Line Crossing Detection | Cross a pre-defined virtual line, up to 4 pre-defined virtual lines supported |
| Intrusion Detection | Enter and loiter in a pre-defined virtual region, up to 4 pre-defined virtual regions supported |
| Region Entrance Detection | Enter a pre-defined virtual region from the outside place |
| Region Exit Detection | Exit from a pre-defined virtual region |
| Object Removal Detection | Objects removed from the pre-defined region, such as the exhibits on display. |
| Unattended Baggage Detection | Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2) |
| Environment Noise Filtering | Support |
| Audio Sampling Rate | Max. 48 kHz |
| Behavior Analysis | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection |
| Region of Interest | Support 4 fixed region for each stream, and dynamic face tracking |
