DS-2CE56D0T-IF

General

Language	English
Operating Condition	-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
Material	Main body: Metal, Enclosure: Plastic
Communication	HIKVISION-C
Dimension	Ø 89.9 mm × 70.1 mm (Ø 3.54" × 2.76")
Power	12 VDC ± 25%, Max. 4 W

Kamera

Image Sensor	2 MP CMOS
Signal System	PAL/NTSC
Max. Resolution	1920 (H) × 1080 (V)
Min. Illumination	0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time	PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night	IR Cut Filter
Angle Adjustment	Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°

Lens

Lens Type	2.8 mm, 3.6 mm Fixed Lens
Focal Length & FOV	103° (2.8 mm), 82.2° (3.6 mm)
Lens Mount	M12

Illuminator

Supplement Light Range

Up to 20 m


Frame Rate	PAL: 1080p@25fps NTSC: 1080p@30fps
Wide Dynamic Range (WDR)	Digital WDR
Image Parameters Switch	STD/HIGH-SAT
Day/Night Mode	Auto/Color/BW (Black and White)
White Balance	Auto
Image Enhancement	DWDR, BLC, Global
Noise Reduction	2D DNR
Image Settings	Brightness, Mirror, Smart IR, Sharpness, AGC

Interface

Video Output

Switchable TVI/AHD/CVI/CVBS

Approval

Protection

IP66
