| Network Storage | NAS (NFS, SMB/ CIFS);ANR |
| Protocols | IPv4/IPv6;HTTP;HTTPS;802.1x;Qos;FTP;SMTP;UPnP;SNMP;DNS;DDNS;NTP;RTSP;RTCP;RTP;TCP/IP;UDP;IGMP;ICMP;DHCP;PPPoE;Bonjour |
| API | Hikvision SDK; ISAPI;Hik-Connect;ISUP;Open Network Video Interface |
| Simultaneous Live View | Up to 20 channels |
| User/Host | 32 |
| Security Measures | Authenticated username and password;MAC address binding;HTTPS encryption;802.1X authenticated access;IP address filter |
| Client | iVMS-4200;Hik-Connect |
| Web Browser | IE10-11, Chrome 57+, Firefox 52+, Safari 12+ |
| Power | 24 VAC, Hi-PoE |
| Power Consumption and Current | Max. 42 W, including max. 15 W for supplement light |
| Operating Conditions | -30℃ to 65℃ (-22°F to 149°F) ;humidity lower than 90%RH |
| SIFIRLA | yes |
| Demist | yes |
| Material | ADC12 |
| Dimensions | Ø 226.1 mm × 362.5 mm (Ø 8.9" × 14.3") |
| Image Sensor | [fixed-focal] 1/1.8" progressive scan CMOS; [varifocal] 1/2.8 progressive scan CMOS" |
| Min. Illumination | [fixed-focal] Color: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with light; [varifocal] Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @(F1.6, AGC ON); 0 Lux with IR |
| Shutter Speed | 1/1 s to 1/30000 s |
| Slow Shutter | yes |
| Focus | semi-auto,manual,auto |
| Day & Night | [fixed-focal] 24/7 colorful imaging; [varifocal] ICR |
| Day/Night Switch | day;night;auto;scheduled-switch |
| BLC | yes |
| WDR | digital WDR |
| HLC | yes |
| 3D DNR | yes |
| Defog | yes |
| EIS | yes |
| Regional Exposure | yes |
| Regional Focus | yes |
| Image Settings | saturation;brightness;contrast;sharpness |
| Image Parameters Switch | yes |
| White Balance | MWB;indoor;outdoor;fluorescent lamp;sodium lamp;ATW;auto;Locked WB |
| Digital Zoom | 16x |
| Optical Zoom | 25x |
| Privacy Mask | up to 24 masks;mosaic mask ;mask color configurable;polygon region |
| DORI | Detect (25px/m): 1600.0 m Observe (63px/m): 634.9 m Recognize (125px/m): 320.0 m Identify (250px/m): 160.0 m |
| SNR | ＞52dB |
| General Function | mirror, password protection, watermark, IP address filter |
| Focal Length | [fixed-focal] 4 mm; [varifocal] 4.8 mm to 120 mm, 25× Optical |
| Zoom Speed | approx. 4.4 s |
| FOV | [fixed-focal] horizontal field of view: 88.7°, vertical field of view: 46.5°, diagonal field of view: 105.0°; [varifocal] Horizontal field of view: 57.6° to 2.5° (wide-tele), Vertical field of view: 34.4° to 1.4° (wide-tele), Diagonal field of view: 64.5° to 2.9° (wide-tele) |
| Aperture | [fixed-focal] F1.0; [varifocal] F1.6 |
| White Light Distance | Up to 30 m |
| IR Distance | Up to 200 m |
| Visual Alarm | White light |
| Region of Interest (ROI) | Fixed region,main stream, sub-stream and third stream respectively support eight fixed areas |
| Max. Resolution | 1920 × 1080 |
| Stream Type | main stream;sub-stream |
| Main Stream | 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 20 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288); 60 Hz: 20 fps (704 × 480, 640 × 480, 352 × 240) |
| Video Compression | H.265;H.264;MJPEG |
| Video Bit Rate | 32 kbps - 16384 kbps |
| H.264 Type | baseline profile;main profile;high profile |
| H.265 Type | main profile |
| H.264+ | yes |
| H.265+ | yes |
| SVC | yes |
| Communication Interface | RJ45, self-adaptive 10M/100M Ethernet port |
| On-board Storage | support microSD/microSDHC/microSDXC cards, up to 256 GB |
| Alarm Input | 2 alarm inputs |
| Alarm Output | 1 alarm output |
| Audio Input | 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10% |
| Audio Output | 1 audio output |
| Alarm Linkage | Preset, patrol scan, pattern scan, memory card video recording, alarm output, sending email, notify surveillance center, upload to FTP, audible warning, white light flashing |
| Protection | IP66, IK10 (excluding glass window), 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Audio Compression | G.711alaw;G.711ulaw;G.722.1;G.726;MP2L2;PCM;AAC |
| Audio Bit rate | MP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps, 192 kbps; AAC: 16 kbps, 32 kbps, 64 kbps;G.722.1: 16Kbps;G.711ulaw: 64Kbps; G.711alaw: 64Kbps |
| Audio Sampling Rate | MP2L2: 16kHz, 32kHz, 48kHz,AAC: 16kHz, 32kHz, 48kHz,PCM: 8kHz, 16kHz, 32kHz, 48kHz |
| Environment Noise Filtering | yes |
| Face Capture | yes |
| Basic Event | audio exception;motion detection;alarm input;alarm output;video tampering alarm;exception |
| Smart Event | intrusion detection;line crossing detection;region entrance detection;region exiting detection;unattended baggage detection;object removal detection |
| Smart Record | ANR;Dual-VCA |
| Warning and Alert | white light warning;audible warning |
| Movement Range (Pan) | 360° |
| Movement Range (Tilt) | -15° to 90° (auto flip) |
| Pan Speed | pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s |
| Tilt Speed | tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s |
| Proportional Zoom | yes |
| Presets | 300 |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans |
| Power-off Memory | yes |
| Park Action | preset;patrol scan;pattern scan;auto scan;tilt scan;random scan;frame scan;panorama scan |
| 3D Positioning | yes |
| PTZ Status Display | yes |
| Preset Freezing | yes |
| Scheduled Task | preset;auto scan;random scan;frame scan;patrol scan;pattern scan;panorama scan;tilt scan;dome reboot;dome adjust;aux output |
