Hikvision
0,00 ₼
| Network Storage | NAS (NFS, SMB/ CIFS); ANR |
| Protocols | IPv4/IPv6;HTTP;HTTPS;802.1x;Qos;FTP;SMTP;UPnP;SNMP;DNS;DDNS;NTP;RTSP;RTCP;RTP;TCP/IP;UDP;IGMP;ICMP;DHCP;PPPoE;Bonjour |
| API | Open-ended API, ONVIF (Profile S, Profile G), ISAPI, Hikvision SDK, Third-party management platform, ISUP |
| Simultaneous Live View | 20 |
| User/Host | 32 |
| Smooth Streaming | yes |
| Security Measures | Authenticated username and password;MAC address binding;HTTPS encryption;802.1X authenticated access;IP address filter |
| Client | iVMS-4200 |
| Web Browser | IE8+ |
| Power | 36 VDC |
| Power Consumption and Current | max. 135 W, including max. 12 W for IR |
| Operating Conditions | Temperature: -40°C to 60°C (-40°F to 140°F)，Humidity: ≤ 95% |
| SIFIRLA | yes |
| Wiper | no |
| De-icing | no |
| Demist | yes |
| Material | ADC12 |
| Dimensions | Φ 391.8mm × 400.5mm (Φ 15.43"×15.77") |
| Image Sensor | [panoramic channel]: 1/1.8" progressive scan CMOS;2/3＂ progressive Scan CMOS |
| Min. Illumination | [panoramic channel] color: 0.0005Lux @ (F1.6, AGC ON), B/W: 0.0001Lux @(F1.6, AGC ON), 0Lux with IR; [PTZ channel] color: 0.005Lux @ (F1.5, AGC ON), B/W: 0.001Lux @(F1.5，AGC ON), 0Lux with IR |
| Shutter Speed | 1~1/30000 |
| Slow Shutter | yes |
| Focus | semi-auto;manual;auto |
| Day & Night | ICR |
| Day/Night Switch | day, night, auto, scheduled-switch |
| BLC | yes |
| WDR | [panoramic channel] No; [PTZ channel] digital WDR |
| HLC | yes |
| 3D DNR | yes |
| Defog | yes |
| EIS | yes |
| OIS | no |
| Regional Exposure | yes |
| Regional Focus | yes |
| Image Settings | saturation;brightness;contrast;sharpness |
| Image Parameters Switch | yes |
| White Balance | auto;ATW;sodium lamp;fluorescent lamp;indoor;outdoor;MWB |
| Digital Zoom | [panoramic channel] no; [PTZ channel] 16x |
| Optical Zoom | 36x |
| Privacy Mask | mask color configurable;rectangle region ;全景8块，细节24块 |
| SNR | ≥55dB |
| Optical Defog | yes |
| Focal Length | [panoramic channel] 2.8mm; [PTZ channel] 7.5-277.5mm |
| Zoom Speed | [panoramic channel] no, [PTZ channel] approx. 7.8 s |
| FOV | [panoramic channel] Horizontal field of view: 2 × 180° Vertical field of view: 85° [PTZ channel] Horizontal field of view: 56.1° to 2.0° (Wide-Tele) Vertical field of view: 33.4° to 1.1° (Wide-Tele) Diagonal field of view: 62.9° to 2.3° (Wide-Tele) |
| Aperture | F1.5 |
| IR Distance | 250 m |
| Smart IR | yes |
| Max. Resolution | 8160*3616 |
| Stream Type | main stream;sub-stream;third stream |
| Main Stream | [panoramic channel] 50Hz: 25fps (32 MP video output mode: 8160 × 3616×2; 8 MP video output mode: 4096 × 1800×2, 3840 × 1680×2, 2720 × 1192×2); 60Hz: 30fps (32 MP video output mode: 8160 × 3616×2; 8 MP video output mode: 4096 × 1800×2, 3840 × 1680×2, 2720 × 1192×2) [PTZ channel] 50Hz: 25fps (4096 × 2160, 3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (4096 × 2160, 3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream | [panoramic channel] 50Hz: 25fps (32 MP video output mode: 3072 × 1280×2, 1560 × 656×2, 704 × 320×2; 8 MP video output mode: 704 × 320×2, 512 × 232×2); 60Hz: 30fps (32 MP video output mode: 3072 × 1280×2, 1560 × 656×2, 704 × 320×2; 8 MP video output mode: 704 × 320×2, 512 × 232×2) [PTZ channel] 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288); 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream | [panoramic channel] 8 MP video output mode: 2048 × 896×2, 1280 × 560×2, 704 × 320×2, 512 × 232×2 [PTZ channel] 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Video Compression | H.265;H.264 |
| H.264+ | yes |
| H.265+ | yes |
| Communication Interface | RJ45;Self-adaptive 10M/100M/1000M Ethernet port |
| Fiber Interface | FC interface;built-in fiber module;TX1310/RX1550nm wavelength;up to 20 km transmission distance;single module fiber;1000M |
| On-board Storage | Built-in microSD slot; support microSD/microSDHC/microSDXC cards;up to 256 GB |
| Alarm Input | 7 alarm inputs |
| Alarm Output | 2 alarm output |
| Audio Input | 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10% |
| Audio Output | 1 audio output, line level, impedance: 600 Ω |
| RS-485 | Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| RS-232 | no |
| Audio Compression | G.711alaw;G.711ulaw;G.722.1;G.726;MP2L2;PCM |
| Audio Sampling Rate | MP2L2: 16kHz, 32kHz, 44.1kHz, 48kHz;PCM: 8kHz, 16kHz, 32kHz, 44.1kHz, 48kHz |
| Smart Event | [Panoramic Channel] Intrusion detection, line crossing detection, region entrance detection, region exiting detection [PTZ Channel] Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection |
| Smart Tracking | manual tracking;panorama tracking;event tracking;support patrol tracking among multiple detection scenes |
| Alarm Linkage | preset;patrol scan;pattern scan;memory card video recording;alarm output;sending email;notify surveillance center; upload to FTP |
| Smart Encoding | H.265+;H.264+;low bit rate;ROI;SVC |
| Movement Range (Pan) | 0-360° |
| Movement Range (Tilt) | -15° to 90° (auto flip) |
| Pan Speed | pan speed: configurable from 0.1° to 210°/s; preset speed: 240°/s |
| Tilt Speed | tilt speed: configurable from 0.1° to 150°/s, preset speed 200°/s |
| Proportional Zoom | [panoramic channel]: no; [PTZ channel]: yes |
| Presets | 300 |
| Patrol Scan | 8 patrols |
| Pattern Scan | 4 pattern scans |
| Power-off Memory | yes |
| Park Action | preset;pattern scan;patrol scan;auto scan;tilt scan;random scan;frame scan;panorama scan |
| 3D Positioning | yes |
| PTZ Status Display | yes |
| Preset Freezing | yes |
| Scheduled Task | preset;pattern scan;patrol scan;auto scan;tilt scan;random scan;frame scan;panorama scan;dome reboot;dome adjust;aux output |
| GPS | no |
| Compass | no |
