| EMC | CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014),RCM (AS/NZS CISPR 32: 2015),IC (ICES-003: Issue 7) |
| Safety | CB (IEC 62368-1: 2014 + A11),CE-LVD (EN 62368-1: 2014/A11: 2017),LOA (IEC/EN 60950-1) |
| Environment | CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No 1907/2006) |
| Protection | IP67 (IEC 60529-2013),TVS 6000 V lightning protection, surge protection and voltage transient protection,IK10 (Excepts Lens) (IEC 62262:2002) |
| Anti-Corrosion Protection | NEMA 4X (NEMA 250-2018) |
| Audio Compression | G.711,G.722.1,G.726,MP2L2,PCM,MP3,AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711),16 Kbps (G.722.1),16 Kbps (G.726),32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3) |
| Audio Sampling Rate | MP2L2: 16 kHz, 32 kHz, 48 kHz,AAC-LC: 16 kHz, 32 kHz, 48 kHz,PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz,MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz |
| Image Sensor | [Bullet channel] 1/1.8" Progressive Scan CMOS, [PTZ channel] 1/1.2" Progressive Scan CMOS |
| Min. Illumination | [Bullet channel] Color: 0.0005 Lux @ (F1.0, AGC ON), [PTZ channel] Color: 0.0005 Lux @ (F1.6, AGC ON), B/W: 0.0001 Lux @ (F1.6, AGC ON), 0 lux with IR |
| Shutter Speed | 1/1 ~ 1/30,000 s |
| Day & Night | [Bullet channel] no, [PTZ channel] IR cut filter |
| Zoom | 60 × optical,16 × digital |
| Max. Resolution | [Panoramic channel] 1920 × 1080, [PTZ channel] 1920 × 1080 |
| Multi-Target-Type Detection | Supports simultaneous detection and capture of human body, face and vehicle |
| Face Capture | Detects up to 30 faces simultaneously |
| Basic Event | Motion detection,video tampering alarm,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error),vandal-proof alam,audio exception detection,alarm input and output |
| Smart Event | Line crossing detection,intrusion detection,region entrance detection,region exiting detection,object removal detection,unattended baggage detection,support alarm triggering by specified target types (human and vehicle) |
| Power | 36 VDC ± 25%, max. 92 W |
| Operating Condition | Temperature: -40°C to 70°C (-40°F to 158°F), Humidity: ≤ 95% |
| Wiper | Yes |
| Language | 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function | Anti-flicker,heartbeat,mirror,flash log,password reset via e-mail,password protection,watermark |
| Dimensions | 491 mm × 338.1 mm × 354.3 mm (19.34" × 13.32" × 13.96") |
| Supplement Light Type | IR Laser (default: off) |
| Supplement Light Range | IR laser distance: up to 1000 m |
| Smart Supplement Light | Yes |
| Wide Dynamic Range (WDR) | 150 dB |
| Image Stabilization | [Panoramic channel]: EIS,[PTZ channel]: OIS |
| Image Enhancement | BLC,HLC,3D DNR |
| Regional Focus | [Panoramic channel] No, [PTZ channel] Yes |
| Defog | Optical defog |
| Regional Exposure | Yes |
| Image Settings | Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser |
| Image Parameters Switch | Yes |
| Privacy Mask | [Panoramic channel] No, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable |
| SNR | ≥ 52 dB |
| Communication Interface | RJ45, self-adaptive 10M/100M Ethernet port |
| On-board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Alarm | 7 input(s), 2 output(s) |
| Audio | 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%, 1 output (line out), line level, output impedance: 600 Ω |
| Focus | Auto,semi-auto,manual |
| Aperture | [Bullet channel] F1.0, [PTZ channel] F1.6 |
| Focal Length | [panoramic channel]: 6 mm [PTZ channel]: 6 to 360 mm: 60× optical |
| FOV | [Panoramic channel] horizontal field of view: 55.2°, vertical field of view: 29.3°, diagonal field of view: 64.8° [PTZ channel] horizontal field of view: 61.1° to 1.4°, vertical field of view: 35.9° to 0.8°, diagonal field of view: 68.5° to 1.6° (W-T) |
| API | ONVIF (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP |
| Security | Password protection,complicated password,host authentication (MAC address),HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),IP address filter |
| Web Browser | IE11, Chrome 80+, Firefox 80+, Safari 13+, Edge 89+ |
| Network Storage | ;NAS (NFS, SMB/ CIFS) |
| Protocols | ;TCP/IP;ICMP;HTTP;FTP;DHCP;DNS;DDNS;RTP;RTSP;RTCP;PPPoE;NTP;SMTP;UPnP;SNMP;IGMP;Qos;UDP;Bonjour;WebSocket;WebSockets |
| User/Host | Up to 32 users. 3 levels: Administrator, Operator and User |
| Client | iVMS-4200 |
| Movement Range (Tilt) | -90° to 90° |
| Pan Speed | Pan speed: configurable from 0.1° to 100°/s, preset speed: 100°/s,Pan speed: configurable up to °/s, preset speed: °/s |
| Tilt Speed | Tilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s |
| 3D Positioning | Yes |
| Scheduled Task | Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,dome adjust,aux output |
| Movement Range (Pan) | 360° |
| Proportional Zoom | [panoramic channel]: no; [PTZ channel]: yes |
| Presets | 300 |
| Patrol Scan | 8 patrols |
| Pattern Scan | 4 pattern scans |
| Power-off Memory | [panoramic channel]: no; [PTZ channel]: yes |
| Park Action | Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan |
| Preset Freezing | [panoramic channel]: no; [PTZ channel]: yes |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264/MJPEG |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 8 fixed regions for each stream |
| Main Stream | [Panoramic channel] 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) [PTZ channel] 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream | [panoramic channel] 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) [PTZ channel] 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288) 60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) |
| Third Stream | [panoramic channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720,704 × 480, 640 × 480, 352 × 240) [PTZ channel] 50 Hz: 25 fps (1920 × 1080,1280 × 960,1280 × 720,704 × 576,640 × 480, 352 × 288) 60 Hz: 30 fps (1920 × 1080,1280 × 960,1280 × 720,704 × 480,640 × 480, 352 × 240) |
