| User capacity | 10,000 |
| Fingerprint capacity | 10,000 |
| Card capacity | 30,000 |
| Event capacity | 100,000 |
| Indicator | 1. Power On: Solid Green 2. Network Armed: Flashing Green, Network Not Armed: Solid Red 3. Serial Port Not Communicating: Light Off, Serial Port Communicating: Solid Green 4. Relay NC: Light Off, Relay NO: Solid Green 5. Network Disconnected: Light Off, Network Cable Connected: Solid Green, Flashing Green |
| Power supply | 12 VDC±15% |
| Working temperature | -10 °C to 55 °C (14 °F to 131 ° F) |
| Working humidity | 0% to 90% (No Condensation) |
| Dimensions | 166.85 mm × 101 mm × 29.5 mm (6.57" × 3.98" × 1.16") |
| Installation | DIN Rail installation |
| Alarm input | 1 Panic Button; 1 Fire Alarm Button; 1 Maintenance Button |
| Alarm output | 2 Relay Outputs |
| RS-485 | 3 |
| Wiegand | 2 |
| Communication protocol | TCP/IP |
| Operating system | Linux |
| Processor | 32 bit |
