| Button | 37 Keys: 3 line keys (BLF keys) with LED indicator; 2 keys for with LED indicator, including: MWI/handset 8 keys, including: Hold/Transfer/Conference/Contact/CallLog/Status/Redial/Mute 4 soft keys 4 navigation keys 1 OK key 12 standard phone digits keys 2 volume control keys (Up/Down) 1 hands-free key |
| Installation | Desktop stand (angles 1: 45°): Wall-mounted |
| Indicator | Red status indicator light for call and message waiting |
| Working temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Working humidity | 10% to 95% (no-condensing) |
| Dimensions | Desktop stand (angles 1: 45°): 169 mm x 186.3 mm x 174.5 mm; desktop stand (angles 2: 50°): 169 mm x 177.6 mm x 183.7 mm; wall-mounted: 169 mm x 115.6 mm x 212.5 mm |
| Power supply | IEEE802.3af, Standard PoE,12 VDC |
| Application environment | Indoor |
| Power consumption | Power consumption (PoE): 1.78 W ~ 5.92 W; power consumption (adapter): 1.28 W ~ 4.31 W |
| Language | English, Simplified Chinese, Traditional Chinese, Russian, Italian, French, German. Hebrew, Spanish, Catalan, Basque, Galician, Turkish, Hungarian, Slovenian, Czech, Korean, Dutch, Ukrainian, Portuguese, Polish |
| Communication Lines | 6 SIP Lines |
| Contact capacity | Local phonebook (1000 entries) Remote phonebook (XML/LDAP, 1000 entries) |
| Call log capacity | In/Out/Missed, 600 entries |
| Operating system | Embedded Linux operation system |
| ROM | 128 MB |
| RAM | 94 MB |
| CPU | Embedded processor |
| Screen size | 2.8-inch |
| Operation method | Physical keys |
| Type | Colorful screen |
| Resolution | 320 x 240 |
| Video decoding | H.264 |
| Video decoding resolution | QVGA / CIF / VGA / 4CIF / 720P / 1080P |
| Audio compression standard | G.711A/U, G.729AB, iLBC, G.722, Opus |
| Audio input | HD voice microphone; HAC handset |
| Audio output | HD voice speaker (handset/hands-free, 0 ~ 7 KHz frequency response) |
| Audio quality | Voice Activity Detection (VAD) / Comfort Noise Generation (CNG) / Background Noise Estimation (BNE) / Noise Reduction (NR)/ Voice quality monitoring |
| Volume adjustment | Adjustable |
| Communication protocol | SIP v1 (RFC2543), v2 (RFC3261) over UDP/TCP/TLS RTP/RTCP/SRTP STUN DHCP IPv6 PPPoE L2TP OpenVPN SNTP FTP/TFTP HTTP/HTTPS TR-069 |
| Wired network | 10/100 Mbps self-adaptive |
| Wi-Fi standard | Wi-Fi 802.11 b/g/n |
| Network interface | 2 RJ-45 10/100 Mbps self-adaptive |
| Power supply input | DC power input |
| Communication interface | 2 RJ-9 ：handset x1, headset x1 |
