Hikvision
0,00 ₼
| Button | 1 |
| Installation | Surface mounting with protective shield |
| Indicator | / |
| Protective level | IP65, IK7 |
| Working temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
| Working humidity | 10% to 90% |
| Dimension (W × H × D) | 150 mm × 82 mm × 23.5 mm (5.91" × 3.23" × 0.93") |
| Battery | / |
| Power supply | 48 VDC, 0.5 A |
| Application environment | Outdoor |
| Power consumption | ≤ 12 W |
| User capacity | / |
| Face capacity | / |
| Fingerprint capacity | / |
| Message capacity | / |
| Linked indoor station capacity | / |
| Operation system | Embedded Analog operation system |
| ROM | / |
| RAM | / |
| Processor | / |
| Screen size | / |
| Operation method | / |
| Type | / |
| Resolution | / |
| Lens | Low Illumination 2 MP HD IR Camera |
| Resolution | Main stream : 1920 × 1080 Sub stream : 720 × 480 |
| FOV | Horizontal: 100°, Vertical: 69° |
| Wide dynamic range (WDR) | Support |
| Supplement light | White light supplement |
| Video compression standard | / |
| Audio input | Built-in omnidirectional microphone |
| Audio compression standard | / |
| Audio output | Built-in loudspeaker (More than 85 dB within 20 cm) |
| Audio compression bitrate | / |
| Audio quality | / |
| Volume adjustment | Adjustable with screwdriver |
| Network protocol | / |
| Wi-Fi | / |
| Bluetooth | / |
| 3G/4G | / |
| Alarm input | 4 |
| Network interface | / |
| TAMPER | 1 |
| Exit button | 2 |
| RS-485 | / |
| USB | / |
| Wiegand | / |
| TF card | / |
| Alarm output | / |
| Lock control | 2 relays, Max. to 30 VDC, 2 A |
| Door contact input | 2 |
| DIP switch | 4 |
