TP-Link

ARCHER C20 - AC750 Wireless Dual Band Router

0,00 ₼

Simultaneous 300 Mbps at 2.4 GHz and 433 Mbps at 5 GHz for 733 Mbps total available bandwidth
Three external antennas provide stable omnidirectional signal and superior wireless coverage
Supports three modes：Router，Range Extender and Access Point Modes
IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize HD streaming
Parental Controls manage when and how connected devices can access the internet
Guest Network provides separate access for guests while securing the host network

Low stock

Standards and Protocols

Wi-Fi 5IEEE 802.11ac/n/a 5 GHzIEEE 802.11n/b/g 2.4 GHz

WiFi Speeds

AC7505 GHz: 433 Mbps (802.11ac)2.4 GHz: 300 Mbps (802.11n)

WiFi Range

2 Bedroom Houses3× Fixed AntennasMultiple antennas form a signal-boosting array to cover more directions and large areas

WiFi Capacity

MediumDual-BandAllocate devices to different bands for optimal performance

Working Modes

Router ModeAccess Point ModeRange Extender Mode

Network Security

SPI FirewallAccess ControlIP & MAC BindingApplication Layer Gateway

Guest Network

1× 5 GHz Guest Network1× 2.4 GHz Guest Network

WiFi Encryption

WEPWPAWPA2WPA/WPA2-Enterprise (802.1x)

Ethernet Ports

1× 10/100 Mbps WAN Port4× 10/100 Mbps LAN Ports

Buttons

WPS/Wi-Fi ButtonPower On/Off ButtonReset Button

Protocols

IPv4IPv6

Parental Controls

URL FilteringTime Controls

WAN Types

Dynamic IPStatic IPPPPoEPPTPL2TP

Quality of Service

QoS by Device

NAT Forwarding

Virtual ServerPort ForwardingPort TriggeringDMZUPnP

IPTV

IGMP ProxyIGMP Snooping

DHCP

Address ReservationDHCP Client ListServer

DDNS

NO-IPComexDynDNS

Management Features

Tether AppWebpageCheck Web Emulator>

Dimensions (W×D×H)

9.1 × 5.7 × 1.4 in(230 × 144 × 35 mm)

Package Content

Wi-Fi Router Archer C20Power AdapterRJ45 Ethernet CableQuick Installation Guide

Certifications

FCC, CE, RoHS

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)Storage Temperature: -40℃~70℃ (-40℉ ~158℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing

Power

9 V ⎓ 0.6 A

System Requirements

Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access)

WiFi Transmission Power

CE:<20dBm(2.4GHz)<23dBm(5GHz)

WiFi Reception Sensitivity

5GHz:11a 54M: -76dBm; 11ac VHT20 MCS8: -71dBm;11ac VHT40 MCS9: -66dBm; 11ac VHT80 MCS9:-62dBm2.4GHz:11g 54M: -76dBm11n; HT20 MCS7: -73dBm;11n HT40 MCS7: -71dBm

Processor

Single-Core CPU
