EAP783 - BE19000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point

HARDWARE FEATURES - Interface

2× 10G Ethernet Ports

HARDWARE FEATURES - Button

Reset

HARDWARE FEATURES - Power Supply

• 802.3bt PoE++ • 12V DCNote：Power adapter is not included.

HARDWARE FEATURES - Max. Power Consumption

39W

HARDWARE FEATURES - Dimensions ( W x D x H )

11.0 x 11.0 x 1.8 in (280 x 280 x 46.5 mm)

HARDWARE FEATURES - Antenna

Internal Omni• 2.4 GHz: 4× 4 dBi• 5 GHz: 4× 5.5 dBi• 6 GHz: 4× 5 dBi

HARDWARE FEATURES - Bluetooth

Yes

HARDWARE FEATURES - Mounting

Ceiling / Wall Mounting (Kits Included)

WIRELESS FEATURES - Coverage

200㎡ (2150 ft²) §

WIRELESS FEATURES - Concurrent Clients

640**

WIRELESS FEATURES - Wireless Standards

IEEE 802.11 a/b/g/n/ac/ax/be

WIRELESS FEATURES - Frequency

6 GHz, 5 GHz, and 2.4 GHz

WIRELESS FEATURES - Signal Rate

• 6 GHz: Up to 11520 Mbps• 5 GHz: Up to 5760 Mbps• 2.4 GHz: Up to 1376 Mbps

WIRELESS FEATURES - Wireless Functions

• MLO• 4K-QAM• 4x4 MU-MIMO DL/UL• HE320 (320 MHz Bandwidth)‡• Mesh§• AI Roaming△• Automatic Channel Selection and Power Adjustment*• BSS Coloring• UL/DL OFDMA• Load Balance• Band Steering• Beamforming• Airtime Fairness• Multiple SSIDS• Wireless Statistics• Wireless Schedule• Reboot Schedule• RADIUS Accounting• MAC Authentication• Static IP/Dynamic IP

WIRELESS FEATURES - Wireless Security

• PPSK• VLAN• Access Control• Rogue AP Detection• Captive Portal Authentication△• Maximum number of MAC Filter: 4,000• Wireless Isolation between Clients• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE

WIRELESS FEATURES - Transmission Power

• CE: <20 dBm (2.4 GHz, EIRP)<23 dBm (5 GHz band 1&band 2, EIRP)<30 dBm (5 GHz band 3, EIRP)<23 dBm (6 GHz EIRP)

Management Features - Omada App

Yes

Management Features - Centralized Management

• Omada Hardware Controller (OC300)• Omada Hardware Controller (OC200)• Omada Software Controller• Omada Cloud-Based Controller

Management Features - Cloud Access

Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller.

Management Features - Email Alerts

Yes

Management Features - LED ON/OFF Control

Yes

Management Features - Management MAC Access Control

Yes

Management Features - SNMP

v1, v2c, v3

Management Features - Web-based Management

Yes

OTHERS - Certification

CE, FCC, RoHS, IC

OTHERS - Package Content

• EAP783• Installation Guide• Ceiling/Wall Mounting Kits

OTHERS - Environment

• Operating Temperature: 0 °C–40 °C (32 °F–104 °F);• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);• Operating Humidity: 10%–90% non-condensing;• Storage Humidity: 5%–90% non-condensing

Management Features - SSH

Yes

Management Features - Restore & Backup

Yes

Management Features - Firmware update via Web

Yes

Management Features - NTP

Yes

GENERAL - Weight

Net Weight:1384.6g
