TP-Link
0,00 ₼
| • 1× 2.5G RJ45 WAN Port• 1× 2.5G RJ45 WAN/LAN Port• 1× Gigabit SFP WAN/LAN Port• 4× Gigabit RJ45 WAN/LAN Ports• 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle) |
| Reset Button |
| 12V/1.5A Adapter |
| 14.2 W (with USB2.0 connected)7.1 W (without USB2.0 connected) |
| 8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) |
| Desktop/Wall Mounting |
| Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| • Omada Cloud-Based Controller• Omada Hardware Controller (OC300)• Omada Hardware Controller (OC200)• Omada Software Controller |
| Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. |
| CE, FCC, RoHS |
| • ER707-M2• Power Adapter• Quick Installation Guide |
| • Operating Temperature: 0–40 ℃ (32–104 ℉);• Storage Temperature: -40–70 ℃ (-40–158 ℉)• Operating Humidity: 10–90% RH non-condensing• Storage Humidity: 5–90% non-condensing |
| Yes. Requiring the use of Omada Cloud-Based Controller. |
| Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux |
| • Automatic Device Discovery• Intelligent Network Monitoring• Abnormal Event Warnings• Unified Configuration• Reboot Schedule• Captive Portal Configuration• ZTP (Zero-Touch Provisioning) |
| Fanless |
| • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q， IEEE802.3bz• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPN |
| • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)• 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)• 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
| Source/Destination IP Based Access Control |
| • WEB Group Filtering§• URL Filtering• Web Security§ |
| • Sending GARP Packets§• ARP Scanning§• IP-MAC Binding§ |
| • TCP/UDP/ICMP Flood Defense• Block TCP Scan (Stealth FIN/Xmas/Null)• Block Ping from WAN |
| 128MB NAND |
| 1 GB DDR4 |
| 500,000 |
| 6,000 |
| 2365.17 Mbps / 2364.45 Mbps |
| 2364.45 Mbps / 2366.04 Mbps |
| 2347.14 Mbps / 2348.29 Mbps |
| 1308.86 Mbps / 974.10 Mbps |
| 1236.27 Mbps / 1280.99 Mbps |
| • ESP-SHA1-AES256: 673.3 Mbps• ESP-SHA256-AES256: 650.2 Mbps• ESP-SHA384-AES256: 629.3 Mbps• ESP-SHA512-AES256: 633.8 Mbps |
| • Unencrypted: 1243.7 Mbps• Encrypted: 561.0 Mbps |
| 132.24 Mbps |
| 1832.69 Mbps / 1741.84 Mbps |
| 2461.18 Mbps / 2457.32 Mbps |
| • IPv4_Static IP• IPv4_Dynamic IP• IPv4_PPPOE• IPv4_L2TP• IPv4_PPTP• IPv6_PPP• IPv6_DHCPv6• IPv6_Static IP• IPv6_6in4• IPv6_Pass-Through• Mobile Broadband: 4G/3G modem for backup via USB port |
| Modify WAN/LAN MAC Address† |
| • DHCP Server• DHCPv6 PD Server (only in Standalone Mode)• DHCP Options Customization• DHCP Address Reservation• Multi-IP Interfaces*• Multi-Net DHCP* |
| StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| 802.1Q VLAN |
| IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| • Static Routing• Policy Routing• RIP (only in Standalone Mode)• OSPF (only in Standalone Mode) |
| • IP/Port-based Bandwidth Control• Guarantee & Limited Bandwidth |
| • Intelligent Load Balance• Application Optimized Routing• Link Backup (Timing§, Failover)• Online Detection |
| • One-to-One NAT§• Multi-Net NAT• Port Forwarding• Port Triggering§• NAT-DMZ• FTP/H.323/SIP/IPSec/PPTP ALG• UPnP |
| IP-based Session Limit |
| • 100 IPSec VPN Tunnels• LAN-to-LAN, Client-to-LAN• Main, Aggressive Negotiation Mode• DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm• IKEv1/v2• MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm• NAT Traversal (NAT-T)• Dead Peer Detection (DPD)• Perfect Forward Secrecy (PFS) |
| • PPTP VPN Server• PPTP VPN Clients (12)• 60 Tunnels (Shared with L2TP)• PPTP with MPPE Encryption |
| • L2TP VPN Server• L2TP VPN Clients (12)• 60 Tunnels (Shared with PPTP)• L2TP over IPSec |
| • OpenVPN Server• OpenVPN Clients (6)• 66 OpenVPN Tunnels* |
| • 20 Tunnels |
| • No Authentication• Simple Password*• Hotspot (Local User/Voucher* /SMS*/Radius*)• External Radius Server• External Portal Server*• LDAP |
| Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe) |
| • Web Management Interface• Remote Management• Export & Import Configuration• SNMP v1/v2c/v3*• Diagnostics (Ping & Traceroute)§• NTP Synchronize§• Port Mirroring• CLI (only in Standalone Mode)• Syslog Support |
| - |
| PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act) |
| 4 kV surge protection |
| Steel |
| TCP: 208 Mbps; UDP: 161 Mbps |
| TCP: 1823 Mbps; UDP: 1272 Mbps |
| √ (Only in Controller Mode) |
| 343Mbps |
