TP-Link

ES210GP - Omada 10-Port Gigabit Easy Managed Switch with 8-Port PoE+

0,00 ₼

10× Gigabit Ports (8× PoE+, 1× RJ45, 1× RJ45/SFP Combo)
63W Total PoE Budget*
Fanless Design for Silent Operation
Easy Centralized Management†
Up to 820ft PoE Transmission**
Remote Camera Reboot‡
Traffic Separation
Traffic Prioritization
Lifetime Free Cloud Without Additional Fees
Manage and Monitor Anytime via App or Web
Unlimited Management Scale for Multiple Sites
Comprehensive Managed Portfolio
Super-Easy Setup with Automatic Device Identification and ZTP
Easy-to-Use Networking for Surveillance Including Remote Camera Reboot
Free Video Monitoring Including Third-Party Camera Management△
Topology, Site Map, and Troubleshooting Tools for Efficient Maintenance
Transmission Distance up to 820ft (250m)**
Priority Video Quality Guaranteed
Secure Traffic Separation via Port Isolation
Remote Camera Reboot†
Surveillance Works with IP Cameras
Wi-Fi Coverage Works with Access Points
Wired Connections Works with Non-PoE Devices such as PCs and Printers

Low stock

HARDWARE FEATURES - Interface

• 8× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+)• 1× 10/100/1000 Mbps RJ45 Port• 1× Gigabit SFP/RJ45 Combo Port• Auto-Negotiation/Auto MDI/MDIX

HARDWARE FEATURES - Power Supply

DC Power Adapter (Output: 53.5V DC / 1.31A)

HARDWARE FEATURES - Dimensions ( W x D x H )

8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)

Management Features - Omada App

Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

Management Features - Centralized Management

• Omada Cloud-Based Controller• Omada Hardware Controller• Omada Software Controller

Management Features - Cloud Access

Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.

OTHERS - Certification

FCC, CE, RoHS

OTHERS - Package Content

• ES210GP• Power Adapter• Power Cord• Installation Guide• Rubber Feet

OTHERS - Environment

• Operating Temperature: 0℃~40℃ (32℉~104℉)• Storage Temperature: -40℃~70℃ (-40℉~158℉)• Operating Humidity: 10%~90% non-condensing• Storage Humidity: 5%~90% non-condensing

Management Features - Zero-Touch Provisioning

Yes. Requires the use of Omada Cloud-Based Controller

HARDWARE FEATURES - Physical Security Lock

√

PERFORMANCE - Packet Buffer Memory

4 Mbit

PERFORMANCE - Jumbo Frame

15 KB

PERFORMANCE - Switching Capacity

20 Gbps

PERFORMANCE - Packet Forwarding Rate

14.88 Mpps

PERFORMANCE - MAC Address Table

Management Features - Management Features

• Web-based GUI• DHCP Client• Cable Diagnostics• Automatic Device Discovery†• Batch Configuration†• Batch Firmware Upgrading†• Unified Configuration†

HARDWARE FEATURES - Fan Quantity

Fanless

SOFTWARE FEATURES - Quality of Service

• Port-based/802.1p/DSCP QoS• 8 Priority Queues• Priority Schedule Mode- WRR (Weighted Round Robin)• Queue Weight Config• Bandwidth Control- Port-Based Rating Limit• Storm Control- Multiple Control Modes (kbps/pps)- Broadcast/Multicast/Unknown-Unicast Control△

SOFTWARE FEATURES - VLAN

• MTU VLAN• Port-Based VLAN• 802.1Q Tag VLAN- Max 32 VLAN Groups- 4K VID

HARDWARE FEATURES - PoE Ports (RJ45)

• Standard: 802.3af PoE and 802.3at PoE+ compliant• PoE Ports: 8 ports• PoE Budget: 63W available for all PoE+ ports, 30W max per port• Remote Camera Reboot†• Up to 820ft (250m) PoE transmission distance**

SOFTWARE FEATURES - L2 Multicast

• IGMP Snooping- IGMP v1/v2/v3 Snooping- Fast Leave

HARDWARE FEATURES - Surge Protection

±6kV

HARDWARE FEATURES - Installation

• Desktop• Wall Mount

SOFTWARE FEATURES - L2 Features

• Static Link Aggregation• Loop Prevention / Loopback Detection• Flow Control- 802.3x Flow Control• Mirroring- Port Mirroring- One-to-One- Many-to-One- Ingress/Egress/Both• Port Statistics- Port Mirror Status- Traffic Statistics• 802.1ab LLDP

SOFTWARE FEATURES - Transmission Method

Store-And-Forward
