TP-Link

RE715X - AX3000 Mesh WiFi 6 Extender

0,00 ₼

Up to 3.0 Gbps Dual Band Wi-Fi: Separates 5 GHz (2402 Mbps) and 2.4 GHz (574 Mbps) WiFi bands for faster speeds and greater capacity with the WiFi 6 technology.†
Smart Roaming: Walk from room to room and stay connected with the fastest possible speeds.§
EasyMesh-Compatible: Flexibly creates a Mesh network by connecting to an EasyMesh-compatible router for seamless whole-home coverage.◇
AP Mode: Create a new WiFi access point through the Gigabit Ethernet port to enhance your wired network with WiFi capability.
Adaptive Path Selection: Automatically choosing the fastest connection path to the router.
Easy Setup: Plug in and then easily set up via a press of the WPS button or via the Tether App.
Ultimate Compatibility: Extends the range of any Wi-Fi router or wireless access point.*

Low stock

Working Modes

Range Extender / Access Point

Package Content

• Wi-Fi Range Extender RE715X • Quick Installation Guide

Environment

• Operating Temperature: 0℃~40℃ (32℉ ~104℉)• Storage Temperature: -40℃~70℃ (-40℉ ~158℉)• Operating Humidity: 10%~90% non-condensing• Storage Humidity: 5%~90% non-condensing

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser

Interface

1 Gigabit Ethernet Port

Button

• WPS Button• Reset Button

Dimensions ( W x D x H )

107×40×160 mm

Antenna

2 External Antennas

Certification

RoHS

Wireless Standards

• IEEE 802.11a/n/ac/ax 5GHz• IEEE 802.11b/g/n/ax 2.4GHz

Frequency

2.4GHz and 5GHz

Signal Rate

• 574 Mbps at 2.4GHz• 2402 Mbps at 5GHz

Reception Sensitivity

5GHz: 11a 6Mbps:-97dBm11a 54Mbps:-78dBm11ax HE20 MCS0: -97dBm 11ax HE20 MCS11: -66dBm11ax HE40 MCS0: -94dBm 11ax HE40 MCS11: -62dBm11ax HE80 MCS0: -92dBm 11ax HE80 MCS11: -61.5dBm 11ax HE160 MCS11: -59dBm 2.4GHz: 11g 6Mbps:-96dBm11g 54Mbps:-78dBm11ax HE20 MCS0: -95dBm 11ax HE20 MCS11: -66dBm11ax HE40 MCS0: -93.5dBm 11ax HE40 MCS11: -62dBm

Wireless Functions

• Enable/Disable Wireless Radio• DFS (the latest firmware and hardware version is required)• Access Control• LED Control• Power Schedule• Wi-Fi Coverage Adjustment

Wireless Security

• WEP• WPA• WPA2• WPA3

Input Power

100-240V~50/60Hz

Transmission Power

• 2.4 GHz ≤ 16 dBm• 5 GHz ≤ 21 dBm

Max. Power Consumption

15.2W

Mesh Technology

EasyMesh-Compatible
