Hikvision

DS-K3H4411-120

Name: REPAIRAZ MMC
Address: Qurban Abbasov 29, Bakı, AZ
Telephone: +994773394100

0,00 ₼

LED indicates the passing direction(forbidden or available).
When the power is cut off, the system will automatically unlock the brake levers into a free-passing mode to facilitate the evacuation of people.
Valid passing duration settings: System will cancel the passing permission if a person does not pass through the lane within the valid passing duration.
There is a DIP switch on the control panel, which adjusts the passage delay time.
Support bi-directional passing through.

Az qalıb

Throughput	More than 30 persons per minute The actual throughput is affected by the person passing rate and passing method.
Lane width	650mm
Pedestal material	SUS304 stainless steel 1.5mm(0.06'') Stainless steel pipe 1.2mm(0.05'')
Power supply	100 to 240 VAC; 50 to 60 Hz
Working temperature	-15℃~55℃(5℉~131℉)
Working humidity	10% to 90% (No Condensing)
Dimensions	Without package: 1630mm x 1580mm x 2300mm(64.2'' x 62.2'' x 90.6'') With package: 2100mm x 1290mm x 1240mm(82.7'' x 50.8'' x 48.9'')
Application environment	Indoor and outdoor
Rotation angle	120°

MCBF	More than 3 million times
Motor	NA
